CT-ERE 1SVR550100R1100 ABB CT-ERE Time relay, ON-delay 1c/o, 0.1-10s, 110-130VAC
CT-ERE
1SVR550100R1100
ABB
1 Pcs.
Automation > Timer relay
CTE Time
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Abb CT-ERE time relay, ON-delay 1c/o, 0.1-10s, 110-130VAC functions as a dedicated electromechanical switching device used to introduce precise, predetermined time delays into industrial control circuits. These components are commonly deployed in automated manufacturing lines, motor starting sequences, and safety interlocks where sequential event timing is critical for proper machinery operation.
Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- EAN: 4013614346163
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85364900
- Replacement Product ID (NEW): 1SVR508100R0000
- Data Sheet, Technical Information: 2CDC111143D0201
- Instructions and Manuals: 1SVC550000M9000
- EPLAN Data: 9AAC201308_EPLAN
- Product Net Width: 22.5 mm
- Product Net Height: 78 mm
- Product Net Depth / Length: 78.5 mm
- Product Net Weight: 0.057 kg
- Timer Relay Type: ON-Delay
- Time Range: 0.1 ... 10 second [unit of time]
- Rated Control Supply Voltage (U s ): 110 ... 130 V AC
- Output: 1 C/O (SPDT) Contact
- Terminal Type: Screw Terminals
More info
▲| Ordering | |
|---|---|
| EAN | 4013614346163 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85364900 |
| Replacement Product ID (NEW) | 1SVR508100R0000 |
| Popular Downloads | |
| Data Sheet, Technical Information | 2CDC111143D0201 |
| Instructions and Manuals | 1SVC550000M9000 |
| EPLAN Data | 9AAC201308_EPLAN |
| Dimensions | |
| Product Net Width | 22.5 mm |
| Product Net Height | 78 mm |
| Product Net Depth / Length | 78.5 mm |
| Product Net Weight | 0.057 kg |
| Technical | |
| Timer Relay Type | ON-Delay |
| Time Range | 0.1 ... 10 second [unit of time] |
| Rated Control Supply Voltage (Us) | 110 ... 130 V AC |
| Output | 1 C/O (SPDT) Contact |
| Terminal Type | Screw Terminals |
| Rated Operational Current AC-12 (Ie) | (230 V) 4 A |
| Rated Operational Current AC-15 (Ie) | (230 V) 3 A |
| Rated Operational Current DC-12 (Ie) | (24 V) 4 A |
| Rated Operational Current DC-13 (Ie) | (24 V) 2 A |
| Mounting Position | 1 ... 6 |
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 |
| TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 | |
| Standards | CAN/CSA C22.2 No.14 |
| IEC/EN 63000 | |
| IEC/EN 61812-1 | |
| UL 508 | |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| RoHS Declaration | 1SVD981002 |
| RoHS Information | Following EU Directive 2011/65/EU |
| Certificates and Declarations | |
| CQC Certificate | CQC2010010303393101 |
| cUL Certificate | cUL508_E140448 |
| Declaration of Conformity - CCC | 2020980303000201 |
| Declaration of Conformity - CE | 1SVD981002 |
| EAC Certificate | EAC_RU_C-DE.ME77.B.02016 |
| RMRS Certificate | RMRS_1740021250 |
| UL Certificate | UL508_E140448 |
| Container Information | |
| Package Level 1 Units | carton 1 piece |
| Package Level 1 Width | 84.2 mm |
| Package Level 1 Depth / Length | 24.6 mm |
| Package Level 1 Height | 83.1 mm |
| Package Level 1 Gross Weight | 0.068 kg |
| Package Level 1 EAN | 4013614346163 |
| External Classifications and Standards | |
| Object Classification Code | K |
| ETIM 7 | EC001439 - Timer relay |
| ETIM 8 | EC001439 - Timer relay |
| ETIM 9 | EC001439 - Timer relay |
| eClass | V11.0 : 27371605 |
| UNSPSC | 39122329 |
| E-Number (Finland) | 2712604 |
