1SVR405663R4000 ABB CR-U 51D Pluggable module RC element, 24-60VAC/DC
1SVR405663R4000
405663
ABB
1 Pcs.
Automation > Accessories/spare parts for switching relay
Plug-in
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Abb 1SVR405663R4000 ABB CR-U 51D Pluggable module RC element, 24-60VAC/DC is a pluggable function module designed to serve as an accessory for interface relays, providing essential spark quenching in industrial control panels. Devices of this type are routinely integrated into relay circuits to suppress voltage spikes, protect contacts, and extend the operational lifespan of switching hardware. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- EAN: 4013614529115
- Minimum Order Quantity: 10 piece
- Customs Tariff Number: 85480090
- Data Sheet, Technical Information: 2CDC110004C0210_05
- Instructions and Manuals: 2CDC117008D0204
- CAD Dimensional Drawing: 2CDC001079B0201
- EPLAN Data: 9AAC132578_EPLAN
- Product Net Width: 34 mm
- Product Net Height: 24 mm
- Product Net Depth / Length: 9 mm
- Product Net Weight: 0.007 kg
- Function: Accessory for interface relays CR-U
- Sub-Function: Pluggable function module for universal relay sockets
- Sub-Function 2: Spark quenching
- Rated Control Supply Voltage (U s ): 24 ... 60 V AC/DC
- Standards: CAN/CSA C22.2 No.14
More info
▲| Ordering | |
|---|---|
| EAN | 4013614529115 |
| Minimum Order Quantity | 10 piece |
| Customs Tariff Number | 85480090 |
| Popular Downloads | |
| Data Sheet, Technical Information | 2CDC110004C0210_05 |
| Instructions and Manuals | 2CDC117008D0204 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| EPLAN Data | 9AAC132578_EPLAN |
| Dimensions | |
| Product Net Width | 34 mm |
| Product Net Height | 24 mm |
| Product Net Depth / Length | 9 mm |
| Product Net Weight | 0.007 kg |
| Technical | |
| Function | Accessory for interface relays CR-U |
| Sub-Function | Pluggable function module for universal relay sockets |
| Sub-Function 2 | Spark quenching |
| Rated Control Supply Voltage (Us) | 24 ... 60 V AC/DC |
| 24 ... 60 V AC | |
| Output Signal | none |
| Standards | CAN/CSA C22.2 No.14 |
| IEC/EN 63000 | |
| IEC/EN 61984 | |
| UL 508 | |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 1SVD981001-4501 |
| RoHS Declaration | 1SVD981001-4401 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006536 |
| Certificates and Declarations | |
| CSA Certificate | CSA_262671_2785566 |
| cURus Certificate | cURus508_E244328 |
| Declaration of Conformity - CE | 1SVD982020-0001 |
| Declaration of Conformity - UKCA | 1SVD982020-1000 |
| EAC Certificate | EAC_RU_C-DE.ME77.B.00446-19 |
| Container Information | |
| Package Level 1 Units | bag 10 piece |
| Package Level 1 Width | 180 mm |
| Package Level 1 Depth / Length | 9 mm |
| Package Level 1 Height | 220 mm |
| Package Level 1 Gross Weight | 0.072 kg |
| Package Level 1 EAN | 4013614383977 |
| External Classifications and Standards | |
| Object Classification Code | K |
| ETIM 7 | EC002586 - Accessories for switching relay |
| ETIM 8 | EC002586 - Accessories/spare parts for switching relay |
| ETIM 9 | EC002586 - Accessories/spare parts for switching relay |
| eClass | V11.0 : 27371692 |
| UNSPSC | 39122331 |
| E-Number (Norway) | 4187777 |
