ABB 1SVR405656R2000 1SVR405656R2000 ABB CR-P/M 82 Pluggable module varistor, without LED, 230VAC View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SVR405656R2000 ABB CR-P/M 82 Pluggable module varistor, without LED, 230VAC

1SVR405656R2000

405656

ABB

1 Pcs.

CR-P/M 82 Pluggable module varistor, without LED, 230VAC Plug-in module CR-P/M 82

Automation > Accessories/spare parts for switching relay
Plug-in

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

1SVR405656R2000 is an Abb pluggable module varistor intended to provide essential overvoltage protection for 230VAC miniature relay sockets in industrial automation systems. Protective modules absorb damaging voltage transients before they can degrade sensitive circuit components, thereby prolonging the service life of control architecture.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • EAN: 4013614528927
  • Minimum Order Quantity: 10 piece
  • Customs Tariff Number: 85480090
  • Data Sheet, Technical Information: 2CDC110004C0210_05
  • Instructions and Manuals: 2CDC110004C0210_05
  • CAD Dimensional Drawing: 2CDC001079B0201
  • EPLAN Data: 9AAC132576_EPLAN
  • Product Net Width: 13 mm
  • Product Net Height: 24 mm
  • Product Net Depth / Length: 9 mm
  • Product Net Weight: 0.002 kg
  • Function: Accessory for interface relays CR-M
  • Sub-Function: Pluggable function module for pcb and miniature relay sockets
  • Sub-Function 2: Overvoltage protection
  • Rated Control Supply Voltage (U s ): 230 V AC
  • Standards: CAN/CSA C22.2 No.14

More info

▲
Ordering
EAN4013614528927
Minimum Order Quantity10 piece
Customs Tariff Number85480090
Popular Downloads
Data Sheet, Technical Information2CDC110004C0210_05
Instructions and Manuals2CDC110004C0210_05
CAD Dimensional Drawing2CDC001079B0201
EPLAN Data9AAC132576_EPLAN
Dimensions
Product Net Width13 mm
Product Net Height24 mm
Product Net Depth / Length9 mm
Product Net Weight0.002 kg
Technical
FunctionAccessory for interface relays CR-M
Accessory for interface relays CR-P
Sub-FunctionPluggable function module for pcb and miniature relay sockets
Sub-Function 2Overvoltage protection
Rated Control Supply Voltage (Us)230 V AC
Output Signalnone
StandardsCAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61984
UL 508
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration1SVD981001-4501
RoHS Declaration1SVD981001-4401
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA2CMT2023-006536
Certificates and Declarations
CSA CertificateCSA_262671_2785566
cURus CertificatecURus508_E244328
Declaration of Conformity - CE1SVD982020-0001
Declaration of Conformity - UKCA1SVD982020-1000
EAC CertificateEAC_RU_C-DE.ME77.B.00446-19
Container Information
Package Level 1 Unitsbag 10 piece
Package Level 1 Width130 mm
Package Level 1 Depth / Length9 mm
Package Level 1 Height180 mm
Package Level 1 Gross Weight0.022 kg
Package Level 1 EAN4013614373985
External Classifications and Standards
Object Classification CodeK
ETIM 7EC002586 - Accessories for switching relay
ETIM 8EC002586 - Accessories/spare parts for switching relay
ETIM 9EC002586 - Accessories/spare parts for switching relay
eClassV11.0 : 27371692
UNSPSC39122331
E-Number (Finland)2712730
E-Number (Norway)4187453
E-Number (Sweden)4005395

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
