1SBN010018R1001 ABB CE5-01W2 Auxiliary Contact Block
1SBN010018R1001
010018
ABB
1 Pcs.
Automation > Auxiliary contact block
"A" FRCTLP
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Abb 1SBN010018R1001 CE5-01W2 Auxiliary Contact Block is an electromechanical switching accessory used to expand the signaling and control capabilities of primary contactors in industrial control panels. Devices of this type mount directly onto switching hardware to provide secondary contact paths for status indication, interlocking, and low-current control logic.
Final pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85389099
- Data Sheet, Technical Information: 1SBC100214C0202
- Instructions and Manuals: 1SBC101013M5501
- Instructions and Manuals (Part 2): 1SAC200017M0002
- CAD Dimensional Drawing: 2CDC001079B0201
- Product Net Width: 9.8 mm
- Product Net Depth / Length: 32.5 mm
- Product Net Height: 46.8 mm
- Product Net Weight: 0.02 kg
- Number of Auxiliary Contacts NO: 0
- Number of Auxiliary Contacts NC: 1
- Number of Poles: 1P
- Standards: IEC/EN 60947-5-1
- Rated Operational Voltage: Auxiliary Circuit 250 V
- Rated Frequency (f): Auxiliary Circuit 50 / 60 Hz
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SBC100214C0202 |
| Instructions and Manuals | 1SBC101013M5501 |
| Instructions and Manuals (Part 2) | 1SAC200017M0002 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Dimensions | |
| Product Net Width | 9.8 mm |
| Product Net Depth / Length | 32.5 mm |
| Product Net Height | 46.8 mm |
| Product Net Weight | 0.02 kg |
| Technical | |
| Number of Auxiliary Contacts NO | 0 |
| Number of Auxiliary Contacts NC | 1 |
| Number of Poles | 1P |
| Standards | IEC/EN 60947-5-1 |
| Rated Operational Voltage | Auxiliary Circuit 250 V |
| Rated Frequency (f) | Auxiliary Circuit 50 / 60 Hz |
| Rated Operational Current AC-15 (Ie) | (24 / 127 V) 2 A |
| (220 / 240 V) 2 A | |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 250 V |
| Connecting Capacity Auxiliary Circuit | Flexible with Ferrule 1/2x 0.75 ... 2.5 mm² |
| Rigid Solid 1/2x 1 ... 4 mm² | |
| Rigid Stranded 1/2x 1 ... 4 mm² | |
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP67 |
| Tightening Torque | Auxiliary Circuit 1 N·m |
| Terminal Type | Screw Terminals |
| Suitable For | AF09 |
| AF09Z | |
| AF12 | |
| AF12Z | |
| AF16 | |
| AF16Z | |
| AF26 | |
| AF26Z | |
| AF30 | |
| AF30Z | |
| AF38 | |
| AF38Z | |
| AF40 | |
| AF52 | |
| AF65 | |
| AF80 | |
| AF96 | |
| AFC09 | |
| AFC12 | |
| AFC16 | |
| AFC26 | |
| AFC30 | |
| AFC38 | |
| NF22E | |
| NFZ22E | |
| NF31E | |
| NFZ31E | |
| NF40E | |
| NFZ40E | |
| NFC22E | |
| NFC31E | |
| NFC40E | |
| A9 | |
| A12 | |
| A16 | |
| A26 | |
| A30 | |
| A40 | |
| A50 | |
| A63 | |
| A75 | |
| A95 | |
| A110 | |
| AL9 | |
| AL9Z | |
| AL12 | |
| AL12Z | |
| AL16 | |
| AL16Z | |
| AL26 | |
| AL30 | |
| AL40 | |
| AE45 | |
| AE50 | |
| AE63 | |
| AE75 | |
| N22E | |
| N31E | |
| N40E | |
| NL31E | |
| NLZ31E | |
| NL40E | |
| NLZ40E | |
| AX06 | |
| AX09 | |
| AX12 | |
| AX18 | |
| AX25 | |
| AX32 | |
| AX40 | |
| AX50 | |
| AX65 | |
| AX80 | |
| NX22E | |
| NX31E | |
| NX40E | |
| Product Name | Auxiliary Contact Block |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| CB Certificate | CB_SE-94569 |
| CQC Certificate | CQC2011010304466171 |
| Declaration of Conformity - CCC | 2020980304001286 |
| Declaration of Conformity - CE | 1SBD250817U1000 |
| Declaration of Conformity - UKCA | 1SBD250834U1000 |
| GOST Certificate | GOST_POCCFRME77B07175 |
| RINA Certificate | RINA_ELE172319XG001 |
| Container Information | |
| Package Level 1 Units | blister 1 piece |
| Package Level 1 Width | 100 mm |
| Package Level 1 Depth / Length | 100 mm |
| Package Level 1 Height | 10 mm |
| Package Level 1 Gross Weight | 0.02 kg |
| Package Level 1 EAN | 3471522199515 |
| Package Level 2 Units | box 126 piece |
| Package Level 2 Width | 245 mm |
| Package Level 2 Depth / Length | 75 mm |
| Package Level 2 Height | 153 mm |
| Package Level 2 Gross Weight | 2.52 kg |
| External Classifications and Standards | |
| Object Classification Code | K |
| ETIM 7 | EC000041 - Auxiliary contact block |
| ETIM 8 | EC000041 - Auxiliary contact block |
| ETIM 9 | EC000041 - Auxiliary contact block |
| eClass | V11.0 : 27371302 |
| UNSPSC | 39121522 |
| IDEA Granular Category Code (IGCC) | 4743 >> Auxiliary contact block |
