1SBN010042R1122 ABB CA5-22MRT Auxiliary Contact Block
1SBN010042R1122
010042
ABB
2 Pcs.
Automation > Accessories/spare parts for low-voltage switch technology
"A" FRCTLP
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Abb 1SBN010042R1122 CA5-22MRT auxiliary contact block mounts directly onto industrial contactors to expand signaling, control, and interlocking capabilities within automation systems. These modular blocks are widely deployed in motor control panels to relay operational states to PLCs or indicator circuits. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 2 piece
- Customs Tariff Number: 85389099
- Data Sheet, Technical Information: 1SBC100122C0202_Ch04
- Instructions and Manuals: 1SBC101011M5501
- CAD Dimensional Drawing: 2CDC001079B0201
- Product Net Width: 43 mm
- Product Net Depth / Length: 39 mm
- Product Net Height: 47 mm
- Product Net Weight: 0.06 kg
- Number of Auxiliary Contacts NO: 2
- Number of Auxiliary Contacts NC: 2
- Number of Poles: 4P
- Rated Operational Voltage: Auxiliary Circuit 690 V
- Rated Frequency (f): Auxiliary Circuit 50 / 60 Hz Rated Operational Current AC-15 (I e ): (500 V) 2 A
- Rated Operational Current DC-13 (I e ): (24 V) 6 A / 144 W
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 2 piece |
| Customs Tariff Number | 85389099 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SBC100122C0202_Ch04 |
| Instructions and Manuals | 1SBC101011M5501 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Dimensions | |
| Product Net Width | 43 mm |
| Product Net Depth / Length | 39 mm |
| Product Net Height | 47 mm |
| Product Net Weight | 0.06 kg |
| Technical | |
| Number of Auxiliary Contacts NO | 2 |
| Number of Auxiliary Contacts NC | 2 |
| Number of Poles | 4P |
| Rated Operational Voltage | Auxiliary Circuit 690 V |
| Rated Frequency (f) | Auxiliary Circuit 50 / 60 Hz |
| Rated Operational Current AC-15 (Ie) | (500 V) 2 A |
| (690 V) 2 A | |
| (24 / 127 V) 6 A | |
| (220 / 240 V) 4 A | |
| (380 / 400 V) 3 A | |
| Rated Operational Current DC-13 (Ie) | (24 V) 6 A / 144 W |
| (48 V) 2.8 A / 134 W | |
| (72 V) 1 A / 72 W | |
| (110 V) 0.55 A / 60 W | |
| (125 V) 0.55 A / 69 W | |
| (220 V) 0.30 A / 66 W | |
| (250 V) 0.3 / 75 W | |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 0.1 s 140 A |
| for 1 s 100 A | |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 690 V |
| acc. to UL/CSA 600 V | |
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP10 |
| Terminal Type | Ring-Tongue Terminals |
| Suitable For | A9 |
| A12 | |
| A16 | |
| A26 | |
| A30 | |
| A40 | |
| AL9 | |
| AL9Z | |
| AL12 | |
| AL12Z | |
| AL16 | |
| AL16Z | |
| AL26 | |
| AL30 | |
| AL40 | |
| TAL9 | |
| TAL12 | |
| TAL16 | |
| TAL26 | |
| TAL30 | |
| TAL40 | |
| Product Name | Auxiliary Contact Block |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| CB Certificate | CB_SE_62119A1 |
| CCC Certificate | CCC_2015010304800518 |
| CQC Certificate | CQC2015010304800518 |
| CQC2004010305133985 | |
| Declaration of Conformity - CCC | 2020980304001627 |
| 2020980305001185 | |
| Declaration of Conformity - CE | 1SBD250809U1000 |
| Declaration of Conformity - UKCA | 1SBD250826U1000 |
| EAC Certificate | EAC_RU C-FR ME77 B03391 |
| GOST Certificate | GOST_POCCFRME77B07175 |
| RINA Certificate | RINA_ELE172319XG001 |
| Container Information | |
| Package Level 1 Units | 2 piece |
| Package Level 1 Width | 65 mm |
| Package Level 1 Depth / Length | 129.5 mm |
| Package Level 1 Height | 43 mm |
| Package Level 1 Gross Weight | 0.12 kg |
| Package Level 1 EAN | 3471522364623 |
| External Classifications and Standards | |
| Object Classification Code | K |
| ETIM 7 | EC000041 - Auxiliary contact block |
| ETIM 8 | EC000041 - Auxiliary contact block |
| ETIM 9 | EC000041 - Auxiliary contact block |
| eClass | V11.0 : 27371302 |
| UNSPSC | 39121522 |
| IDEA Granular Category Code (IGCC) | 4743 >> Auxiliary contact block |
