View larger
Images are for illustrative purposes only. Please refer to data sheet for details
1SBN110122T1000 ABB BDT4 Test Block
1SBN110122T1000
110122
ABB
1 Pcs.
BDT4 Test Block
BDT4 MECHANICAL TEST PART CONTACTORS
Automation > Accessories/spare parts for low-voltage switch technology
AF contactors 40A to 100A
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 10 piece |
| Customs Tariff Number | 85369010 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SBC100214C0202 |
| Instructions and Manuals | 1SBC101042M6801 |
| Instructions and Manuals (Part 2) | 1SAC200017M0002 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Dimensions | |
| Product Net Width | 29 mm |
| Product Net Depth / Length | 24 mm |
| Product Net Height | 22 mm |
| Product Net Weight | 0.074 kg |
| Technical | |
| Suitable For | AS09 |
| AS12 | |
| AS16 | |
| ASL09 | |
| ASL12 | |
| ASL16 | |
| NS22E | |
| NS31E | |
| NS40E | |
| NS44E | |
| NS53E | |
| NS62E | |
| NS71E | |
| NS80E | |
| NSL22E | |
| NSL31E | |
| NSL40E | |
| NSL44E | |
| NSL53E | |
| NSL62E | |
| NSL71E | |
| NSL80E | |
| VAS09 | |
| VAS12 | |
| VAS16 | |
| VASL09 | |
| VASL12 | |
| VASL16 | |
| AF09 | |
| AF09Z | |
| AF12 | |
| AF12Z | |
| AF16 | |
| AF16Z | |
| AF26 | |
| AF26Z | |
| AF30 | |
| AF30Z | |
| AF38 | |
| AF38Z | |
| AF40 | |
| AF52 | |
| AF65 | |
| AF80 | |
| AF96 | |
| AFC09 | |
| AFC12 | |
| AFC16 | |
| AFC26 | |
| AFC30 | |
| AFC38 | |
| AFC40 | |
| AFC52 | |
| AFC65 | |
| AFC80 | |
| AFC96 | |
| AF09B | |
| AF09ZB | |
| AF12B | |
| AF12ZB | |
| AF16B | |
| AF16ZB | |
| AF26B | |
| AF26ZB | |
| AF30B | |
| AF30ZB | |
| AF38B | |
| AF38ZB | |
| AF40B | |
| AF52B | |
| AF65B | |
| AF80B | |
| AF96B | |
| NF22E | |
| NFZ22E | |
| NF31E | |
| NFZ31E | |
| NF40E | |
| NFZ40E | |
| NFC22E | |
| NFC31E | |
| NFC40E | |
| NFZB22E | |
| NFB22E | |
| NFZB31E | |
| NFB31E | |
| NFZB40E | |
| NFB40E | |
| Product Name | Test Block |
| Environmental | |
| Maximum Operating Altitude Permissible | Without Derating 3000 m |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 1SBD250060U1000 |
| Declaration of Conformity - UKCA | 1SBD250061U1000 |
| GOST Certificate | GOST_POCCFR.ME77.B07175.pdf |
| Container Information | |
| Package Level 1 Units | bag 10 piece |
| Package Level 1 Width | 160 mm |
| Package Level 1 Depth / Length | 65 mm |
| Package Level 1 Height | 30 mm |
| Package Level 1 Gross Weight | 0.74 kg |
| Package Level 1 EAN | 3471523131026 |
| Package Level 2 Units | box 100 piece |
| Package Level 2 Width | 500 mm |
| Package Level 2 Depth / Length | 310 mm |
| Package Level 2 Height | 160 mm |
| Package Level 2 Gross Weight | 0.74 kg |
| External Classifications and Standards | |
| ETIM 7 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| ETIM 9 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| UNSPSC | 39122221 |
| IDEA Granular Category Code (IGCC) | 5219 >> Switch part or accessory |
| E-Number (Finland) | 3707158 |
| Feature Name | Feature Value |
|---|---|
| Type of accessory/spare part (EF000215) | Mechanical locking |
| Accessory (EF013236) | Yes |
| Spare part (EF013237) | No |
