View larger
Images are for illustrative purposes only. Please refer to data sheet for details
2TLA920509R0001 ABB HD5-M-001 support
2TLA920509R0001
920509
ABB
1 Pcs.
HD5-M-001 support
HD5-M-001 Bracket
Automation > Accessories/spare parts for agreement switch
Fences and rolling doors
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Product Main Type | HD5 accessory |
| Product Name | Bracket |
| Popular Downloads | |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Dimensions | |
| Product Net Depth / Length | 90 mm |
| Product Net Height | 60 mm |
| Product Net Width | 75 mm |
| Product Net Weight | 0.06 kg |
| Dimension Diagram | 2CDC172111D0201 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Technical | |
| Suitable For | HD5 |
| Environmental | |
| Material | Fiberglass reinforced plastic |
| PPH G30 | |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2022-006480 |
| RoHS Declaration | 2CMT2022-006499 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006522 |
| WEEE Category | Product Not in WEEE Scope |
| Certificates and Declarations | |
| TÜV Certificate | 2TLC010054D0201 |
| 2TLC010053D0201 | |
| Container Information | |
| Package Level 1 Units | bag 1 piece |
| Package Level 1 Width | 75 mm |
| Package Level 1 Depth / Length | 90 mm |
| Package Level 1 Height | 60 mm |
| Package Level 1 Gross Weight | 0.06 kg |
| Package Level 1 EAN | 4013614563621 |
| External Classifications and Standards | |
| eClass | V11.0 : 27371392 |
| ETIM 7 | EC002886 - Accessories for agreement switch |
| ETIM 8 | EC002886 - Accessories/spare parts for agreement switch |
| ETIM 9 | EC002886 - Accessories/spare parts for agreement switch |
| E-Number (Sweden) | 3833805 |
| Feature Name | Feature Value |
|---|---|
| Type of accessory/spare part (EF000215) | Mounting bracket |
| Accessory (EF013236) | No |
| Spare part (EF013237) | No |
