View larger
Images are for illustrative purposes only. Please refer to data sheet for details
2CSS252421R0045 ABB Int.aut. S202TC-B4 2 4A B 6 kA
2CSS252421R0045
252421
ABB
1 Pcs.
Int.aut. S202TC-B4 2 4A B 6 kA
Miniature Circuit Breaker - S200C Enhancement - 2P - 4 A - B - (230 V) 6 kA
Automation > Miniature circuit breaker (MCB)
Tertiary / Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| EcoSolutions Profile | 9AKK108471A1276 |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 88.23 % |
| Material Resource Reduction (wt. %) | Design for Reduced Resource Consumption - 43.18 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| UL 2799 Zero Waste To Landfill Validation available | |
| Sustainable Material Content in Packaging (wt. %) | FSC Mix Cardboard - 100 % |
| Improved Energy Efficiency for Customers | Product Efficiency - Product considered more energy-efficient compared to similar product on market or older products from the same line |
| Product Efficiency - Product requires less energy to operate compared to similar product on market or older products from the same line | |
| Process Efficiency - Product improves/optimizes process | |
| Process Efficiency - Product contribute to reducing customer operations environmental footprint | |
| Extended Product Lifetime | Product Durability |
| End Of Life Disassembling Instructions | 9AKK108471A1270 |
| Environmental Product Declaration - EPD | 9AKK108471A1273 |
| Technical | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (240 / 415 V AC) 7.5 kA |
| Contact Position Indication | ON / OFF |
| Energy Limiting Class | 3 |
| Electrical Endurance | 7000 cycle |
| Mechanical Endurance | 7000 cycle |
| Number of Protected Poles | 2 |
| Number of Poles | 2P |
| Tightening Torque | 1.2 N·m |
| Screw Terminal Type | Cage Terminal |
| Actuator Marking | I / O |
| Accessories Available | Yes |
| Connecting Capacity | Flexible 1 ... 10 mm² |
| Rigid 1 ... 16 mm² | |
| Wire Stripping Length | 10 mm |
| Terminal Type | Screw Terminals |
| Electrical | |
| Tripping Characteristic | B |
| Rated Operational Voltage | acc. to IEC 60898-1 240 V |
| Operational Voltage | 253 V |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Input Voltage Type | AC |
| Rated Current (In) | 4 A |
| Rated Short-Circuit Capacity | (230 V) 6 kA |
| Rated Frequency (f) | 50 ... 60 Hz |
| Power Loss | Total 3.8 W |
| Overvoltage Category | III |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Environmental | |
| Ambient Air Temperature | Operation -25 ... 55 °C |
| Degree of Protection | IP20 |
| Pollution Degree | 2 |
| Dimensions | |
| Width in Number of Modular Spacings | 1 |
| Product Net Width | 17.6 mm |
| Product Net Height | 85 mm |
| Product Net Depth / Length | 69 mm |
| Product Net Weight | 120 g |
| Built-In Depth (t2) | 69.4 mm |
| Ordering | |
| Package Level 1 Units | box 6 piece |
| Package Level 1 Gross Weight | 720 g |
| E-Number (Sweden) | 2101654 |
| External Classifications and Standards | |
| ETIM 9 | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 10 | EC000042 - Miniature circuit breaker (MCB) |
| Standards | IEC/EN 60898-1 |
