Images are for illustrative purposes only. Please refer to data sheet for details
2CSS242420R0044 ABB Int.aut. S202CL-C4 2 4A C 4.5 kA
2CSS242420R0044
242420
ABB
1 Pcs.
Int.aut. S202CL-C4 2 4A C 4.5 kA
Miniature Circuit Breaker - S200C Enhancement - 2P - 4 A - C - (230 V) 4.5 kA
Automation > Miniature circuit breaker (MCB)
Residential / Tertiary
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Abb part number 2CSS242420R0044 is an integrated automatic circuit breaker from the S200CL line, built to guard electrical circuits from overloads and short circuits. Such modular protective components are standard in industrial and residential switchboards to ensure reliable fault isolation.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- EcoSolutions Profile: 9AKK108471A1276
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 88.23 %
- Material Resource Reduction (wt. %): Design for Reduced Resource Consumption - 43.18 %
- ABB Site Meeting Group Waste To Landfill Target: No non-hazardous waste is sent to a landfill
- Sustainable Material Content in Packaging (wt. %): FSC Mix Cardboard - 100 %
- Extended Product Lifetime: Product Durability
- End Of Life Disassembling Instructions: 9AKK108471A1270
- Environmental Product Declaration - EPD: 9AKK108471A1273
- Rated Service Short-Circuit Breaking Capacity (I cs ): (240 / 415 V AC) 7.5 kA
- Contact Position Indication: ON / OFF
- Energy Limiting Class: 3
- Electrical Endurance: 7000 cycle
- Mechanical Endurance: 7000 cycle
- Number of Protected Poles: 2
- Number of Poles: 2P
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| EcoSolutions Profile | 9AKK108471A1276 |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 88.23 % |
| Material Resource Reduction (wt. %) | Design for Reduced Resource Consumption - 43.18 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| UL 2799 Zero Waste To Landfill Validation available | |
| Sustainable Material Content in Packaging (wt. %) | FSC Mix Cardboard - 100 % |
| Improved Energy Efficiency for Customers | Product Efficiency - Product considered more energy-efficient compared to similar product on market or older products from the same line |
| Product Efficiency - Product requires less energy to operate compared to similar product on market or older products from the same line | |
| Process Efficiency - Product improves/optimizes process | |
| Process Efficiency - Product contribute to reducing customer operations environmental footprint | |
| Extended Product Lifetime | Product Durability |
| End Of Life Disassembling Instructions | 9AKK108471A1270 |
| Environmental Product Declaration - EPD | 9AKK108471A1273 |
| Technical | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (240 / 415 V AC) 7.5 kA |
| Contact Position Indication | ON / OFF |
| Energy Limiting Class | 3 |
| Electrical Endurance | 7000 cycle |
| Mechanical Endurance | 7000 cycle |
| Number of Protected Poles | 2 |
| Number of Poles | 2P |
| Tightening Torque | 1.2 N·m |
| Screw Terminal Type | Cage Terminal |
| Actuator Marking | I / O |
| Accessories Available | Yes |
| Connecting Capacity | Flexible 1 ... 10 mm² |
| Rigid 1 ... 16 mm² | |
| Wire Stripping Length | 10 mm |
| Terminal Type | Screw Terminals |
| Electrical | |
| Tripping Characteristic | C |
| Rated Operational Voltage | acc. to IEC 60898-1 240 V |
| Operational Voltage | 253 V |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Input Voltage Type | AC |
| Rated Current (In) | 4 A |
| Rated Short-Circuit Capacity | (230 V) 4.5 kA |
| Rated Frequency (f) | 50 ... 60 Hz |
| Power Loss | Total 2.6 W |
| Overvoltage Category | III |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| Environmental | |
| Ambient Air Temperature | Operation -25 ... 55 °C |
| Degree of Protection | IP20 |
| Pollution Degree | 2 |
| Dimensions | |
| Width in Number of Modular Spacings | 1 |
| Product Net Width | 17.6 mm |
| Product Net Height | 85 mm |
| Product Net Depth / Length | 69 mm |
| Product Net Weight | 120 g |
| Built-In Depth (t2) | 69.4 mm |
| Ordering | |
| Package Level 1 Units | box 6 piece |
| Package Level 1 Gross Weight | 720 g |
| E-Number (Sweden) | 2101548 |
| External Classifications and Standards | |
| ETIM 9 | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 10 | EC000042 - Miniature circuit breaker (MCB) |
| Standards | IEC/EN 60898-1 |
