View larger
Images are for illustrative purposes only. Please refer to data sheet for details
2CSG239145R4051 ABB Anal. network. M4M 2X ETHERNET RTS
2CSG239145R4051
239145
ABB
1 Pcs.
Anal. network. M4M 2X ETHERNET RTS
M4M 2X ETHERNET RTS Network analyzer
Automation > Kilowatt-hour meter
AER and Transformers
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| EcoSolutions Profile | 9AKK108470A1669 |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 54.85 % |
| Material Resource Reduction (wt. %) | Design for Reduced Resource Consumption - 22 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| UL 2799 Zero Waste To Landfill Validation available | |
| Improved Energy Efficiency for Customers | Product Efficiency - Product considered more energy-efficient compared to similar product on market or older products from the same line |
| Product Efficiency - Product requires less energy to operate compared to similar product on market or older products from the same line | |
| Process Efficiency - Product improves/optimizes process | |
| Process Efficiency - Product contribute to making customer’s operations more resilient and reliable | |
| Process Efficiency - Product contribute to reducing customer operations environmental footprint | |
| Digital Efficiency - Product is digitally-supported to optimize usage and eventually optimize customer asset | |
| Extended Product Lifetime | Product Upgradability |
| Lifetime extension of customer’s assets is made possible thanks to offering and the supporting services | |
| End Of Life Disassembling Instructions | 9AKK108470A0840 |
| Environmental Product Declaration - EPD | 9AKK108469A8099 |
| Technical | |
| Sub-Function | RTS |
| Current Rating | 5 A |
| Accuracy | Active Energy ±0.5% |
| Measuring Instrument Conformity | Domestic |
| Meter Tariff Control | Internal |
| External | |
| Meter Tariff Rating | Multi-Tariff |
| Pulse Output Rate | 1 … 999999 |
| Model Number | Measurement transformer |
| Number of Poles | 3P or 4P |
| Number of Phases | 3-phase |
| Number of Counter Positions | 9 |
| Number of Digital In/Outputs | 4 Programmable Inputs/Outputs |
| Energy Meter Type | Effective Power |
| Blind Power | |
| Meter Type | Digital |
| Purchase/supply | |
| Type of Indicator | Digital |
| Additional Information | CT (1A, 5A) |
| Communication | Modbus TCP/IP, Bluetooth |
| Electrical | |
| Rated Voltage (Ur) | 3 x 230 (400) V |
| Voltage Range | 50 … 400 V |
| Rated Current (In) | 5 A |
| Maximum 6 A | |
| Frequency (f) | 50 … 60 Hz |
| Material Compliance | |
| RoHS Declaration | 9AKK108467A6267 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20210609 |
| REACH Information | No data - If REACH inform is not yet available for a certain product |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Business |
| Environmental | |
| Degree of Protection | IP20 |
| Dimensions | |
| Width in Number of Modular Spacings | 5.5 |
| Product Net Width | 96 mm |
| Product Net Height | 96 mm |
| Product Net Depth / Length | 78 mm |
| Product Net Weight | 355 g |
| Ordering | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 0.50 kg |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 9AKK108467A6267 |
| EU Data Act Compliance Declaration | 9AKK108471A5057 |
| Installation | |
| Instructions and Manuals | 2CSG445043D0201 |
| Mounting Type | DIN-Rail |
| Popular Downloads | |
| Data Sheet, Technical Information | 9AKK107992A0896 |
| External Classifications and Standards | |
| ETIM 9 | EC001506 - Kilowatt-hour meter |
| ETIM 10 | EC001506 - Electricity meter |
| eClass | V11.0 : 27142316 |
| Feature Name | Feature Value |
|---|---|
| Type of meter (EF005441) | Electronic |
| Nominal current (In) (EF008873) | 6 A |
| Max. current (Imax) (EF000877) | 6 A |
| Frequency (EF000416) | 50 Hz |
| Pole type (EF008843) | Three conductor/four conductor |
| Model (EF000010) | Measurement transformer |
| Energy type (EF007135) | Effective power and reactive power |
| Tariff type (EF007550) | Multi-tariff |
| Tariff control (EF008834) | Internal/external |
| Measurement type load profile (EF008844) | No |
| Escapement mechanism (EF008835) | Yes |
| Calibrated (EF008836) | Yes |
| Approval (EF008837) | Domestic |
| Type of indication (EF000306) | Digital |
| Mounting method (EF000003) | DRA (DIN-rail adapter) |
| Width in number of modular spacings (EF002950) | 5.5 |
| Width (EF000008) | 96 mm |
| Depth (EF000049) | 78 mm |
| Height (EF000040) | 96 mm |
| EEC40 signature (EF008845) | No |
| With lock code (EF008846) | No |
| Number of positions total (counter) (EF004442) | 9 |
| Degree of protection (IP) (EF005474) | IP20 |
