Images are for illustrative purposes only. Please refer to data sheet for details
2CSF204998R0035 ABB Reconnect. leak check F3C-AR230 C 4/300
2CSF204998R0035
204998
ABB
1 Pcs.
Reconnect. leak check F3C-AR230 C 4/300
Autoreclosing unit with system check F3C-AR
Automation > Auxiliary device for distribution board devices
Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
2CSF204998R0035 ABB Reconnect. leak check F3C-AR230 C 4/300 supplied by Abb functions as an auxiliary switch and relay unit designed for automated leakage monitoring and resetting workflows in electrical installations.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Environmental Product Declaration - EPD: 9AKK108470A7409
- Suitable For: F204 300 mA up to 100A
- Suitable for Product Class: Auxiliary switch/relay
- Mechanical Endurance: 5000 cycle
- Tightening Torque: 0.4 N·m
- Mounting Position of Accessories: Right
- Number of Batteries: 0
- Cable Size: 0.2 … 2.5 mm²
- Wire Stripping Length: 5 mm
- Terminal Type: Plug-in Connection
- Rated Voltage (U r ): 230 … 240 V
- Rated Operational Voltage: 230-240 (-15% +10%) V AC
- Supply Voltage: 230-240 V AC V
- Input Voltage Type: AC
- Power Consumption (@P cons ): <20 W
- Overvoltage Category: III
More info
▲| ABB EcoSolutions | |
|---|---|
| Environmental Product Declaration - EPD | 9AKK108470A7409 |
| Technical | |
| Suitable For | F204 300 mA up to 100A |
| F200 B Type up to 63A | |
| Suitable for Product Class | Auxiliary switch/relay |
| Mechanical Endurance | 5000 cycle |
| Tightening Torque | 0.4 N·m |
| Mounting Position of Accessories | Right |
| Number of Batteries | 0 |
| Cable Size | 0.2 … 2.5 mm² |
| Wire Stripping Length | 5 mm |
| Terminal Type | Plug-in Connection |
| Electrical | |
| Rated Voltage (Ur) | 230 … 240 V |
| Rated Operational Voltage | 230-240 (-15% +10%) V AC |
| Supply Voltage | 230-240 V AC V |
| Input Voltage Type | AC |
| Power Consumption (@Pcons) | <20 W |
| Overvoltage Category | III |
| Design | |
| Number of Modules | 1.5 |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Consumer |
| Environmental | |
| Ambient Air Temperature | Operation -25 …+60 °C |
| Degree of Protection | Housing IP40 |
| Terminals IP20 | |
| Pollution Degree | 2 |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 1g 5 … 150 … 5 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g 2 shocks 13 ms |
| Dimensions | |
| Width in Number of Modular Spacings | 1.5 |
| Product Net Width | 81.5 mm |
| Product Net Height | 104.15 mm |
| Product Net Depth / Length | 58.3 mm |
| Product Net Weight | 130 g |
| Dimension Diagram | 9AKK108470A2467 |
| Ordering | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Gross Weight | 0.150 kg |
| Installation | |
| Instructions and Manuals | 9AKK108470A1492 |
| Mounting Position | Left |
| Popular Downloads | |
| Electrical Drawings | 9AKK108470A2370 |
| External Classifications and Standards | |
| ETIM 9 | EC001286 - Auxiliary device for distribution board devices |
| ETIM 10 | EC001286 - Auxiliary device for distribution board devices |
| Standards | IEC63024 |
