ABB 2CPX068572R9999 2CPX068572R9999 ABB ED112 Bast. EDF, high and low, 2A View larger
Images are for illustrative purposes only. Please refer to data sheet for details

2CPX068572R9999 ABB ED112 Bast. EDF, high and low, 2A

2CPX068572R9999

068572

ABB

1 Pcs.

ED112 Bast. EDF, high and low, 2A 34 mm x 500 mm x 15.5 mm , 2

Automation > Profile (switchgear cabinet)
Boxes and cabinets

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

2CPX068572R9999 ABB ED112 Bast. EDF, high and low, 2A serves as an internal modular mounting framework component used in electrical distribution enclosures to securely position panel-building equipment. Such rails provide dependable structural support for complex wiring and modular device layouts.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Model Number: Mounting rail
  • Enclosure Type: Slide rails
  • Meter Type: "
  • DIN Place Units: 0
  • Meter Boards: 0
  • Surface Finishing: Galvanised
  • Material: Steel
  • RoHS Declaration: 2CPC100019X0201
  • RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
  • RoHS Date: 20240903
  • REACH Declaration: 2CPC100005X0201
  • REACH Information: False - does not contain substances > 0.1 mass percentage
  • REACH Date: 20240902
  • Conflict Minerals Reporting Template (CMRT): 9AKK108468A3363
  • WEEE Category: Product Not in WEEE Scope
  • Product Net Width: 500 mm

More info

▲
Technical
Model NumberMounting rail
Enclosure TypeSlide rails
Meter Type"
DIN Place Units0
Meter Boards0
Design
Surface FinishingGalvanised
MaterialSteel
Material Compliance
RoHS Declaration2CPC100019X0201
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date20240903
REACH Declaration2CPC100005X0201
REACH InformationFalse - does not contain substances > 0.1 mass percentage
REACH Date20240902
Conflict Minerals Reporting Template (CMRT)9AKK108468A3363
WEEE CategoryProduct Not in WEEE Scope
Dimensions
Product Net Width500 mm
Product Net Height34 mm
Product Net Depth / Length15.5 mm
Product Net Weight0.378 kg
Section Width2
Ordering
Package Level 1 Unitspack 1 piece
Package Level 1 Gross Weight0.393 kg
Certificates and Declarations
Declaration of Conformity - CE2CPC100019X0201
Installation
Instructions and Manuals2CPC112313M5601
Mounting TypeScrew mounting
Mounting Positionhorizontal
Popular Downloads
Data Sheet, Technical Information2CPC000001C0101
2CPC000002C0101
External Classifications and Standards
ETIM 9EC002518 - Profile (enclosure/cabinet)
ETIM 10EC002518 - Profile (enclosure/cabinet)
eClassV11.0 : 27180907
Object Classification CodeU

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
