2CDS381001R0041 ABB Int.aut. S301P-D4 1p 4A D 25kA
2CDS381001R0041
381001
ABB
1 Pcs.
Int.aut. S301P-D4 1p 4A D 25kA
Miniature Circuit Breaker - S300P - 1P - 4 A - D - (AC) 25 kA
Automation > Miniature circuit breaker (MCB)
Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Abb circuit breaker (2CDS381001R0041) is integrated into high-demand electrical systems to interrupt fault currents and prevent catastrophic equipment damage. Reliable circuit protection ensures continuous safety across industrial installations.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- EcoSolutions Profile: 9AKK108469A3274
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 63.8 %
- Extended Product Lifetime: Product Durability
- End Of Life Disassembling Instructions: 9AKK108467A9801
- Environmental Product Declaration - EPD: 9AKK108467A7130
- Dielectric Test Voltage: 50 / 60 Hz - 1 min 2 kV
- Rated Ultimate Short-Circuit Breaking Capacity (I cu ): (230 V AC) 100 kA
- Rated Service Short-Circuit Breaking Capacity (I cs ): (230 V AC) 100 kA
- Power Supply Connection: Arbitrary
- Contact Position Indication: Red ON / Green OFF
- Electrical Endurance: 20000 AC cycle
- Mechanical Endurance: 20000 cycle
- Number of Protected Poles: 1
- Number of Poles: 1P
- Tightening Torque: 2.8 N·m
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| EcoSolutions Profile | 9AKK108469A3274 |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 63.8 % |
| Improved Energy Efficiency for Customers | Product Efficiency - Product requires less energy to operate compared to similar product on market or older products from the same line |
| Extended Product Lifetime | Product Durability |
| End Of Life Disassembling Instructions | 9AKK108467A9801 |
| Environmental Product Declaration - EPD | 9AKK108467A7130 |
| Technical | |
| Dielectric Test Voltage | 50 / 60 Hz - 1 min 2 kV |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (230 V AC) 100 kA |
| (240 V AC) 100 kA | |
| (72 V DC) 100 kA | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (230 V AC) 100 kA |
| (240 V AC) 100 kA | |
| (72 V DC) 100 kA | |
| Power Supply Connection | Arbitrary |
| Contact Position Indication | Red ON / Green OFF |
| Electrical Endurance | 20000 AC cycle |
| Mechanical Endurance | 20000 cycle |
| Number of Protected Poles | 1 |
| Number of Poles | 1P |
| Tightening Torque | 2.8 N·m |
| Actuator Type | Toggle |
| Screw Terminal Type | Failsafe Bi-directional Cylinder-lift Terminal |
| Actuator Marking | I / O |
| Actuator Material | Insulation Group II, Black, Sealable |
| Recommended Screw Driver | Pozidriv 2 |
| Accessories Available | Yes |
| Connecting Capacity | Busbar 10/10 mm² |
| Flexible with Ferrule 0.75 ... 25 mm² | |
| Flexible 0.75 ... 25 mm² | |
| Flexible 0.75 ... 25 mm² | |
| Rigid 0.75 ... 35 mm² | |
| Stranded 0.75 ... 35 mm² | |
| Installation Size | acc. to DIN 43880 1 |
| Wire Stripping Length | 14 mm |
| Terminal Type | Screw Terminals |
| Electrical | |
| Tripping Characteristic | D |
| Rated Operational Voltage | acc. to IEC 60898-1 240 V AC |
| acc. to IEC 60947-2 240 V AC | |
| Operational Voltage | Maximum (Incl. Tolerance) 254 V AC |
| Maximum 254 V AC | |
| Minimum 12 V AC | |
| Minimum 12 V DC | |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 500 V |
| Rated Impulse Withstand Voltage (Uimp) | 6 kV |
| Input Voltage Type | AC/DC |
| Rated Current (In) | 4 A |
| Rated Short-Circuit Capacity | (AC) 25 kA |
| (230 V AC) 100 kA | |
| (240 / 415 V AC) 25 kA | |
| (240 V AC) 100 kA | |
| Rated Frequency (f) | 50 / 60 Hz |
| DC | |
| Power Loss | 1.4 W |
| at Rated Operating Conditions per Pole 1.4 W | |
| Overvoltage Category | IV |
| Design | |
| Housing Material | Insulation Group I, RAL 7035 |
| Technical UL/CSA | |
| Maximum Operating Voltage UL/CSA | 480Y / 277 V AC |
| 480Y/277 V AC | |
| Interrupting Rating acc. to UL1077 | (277 V AC) 10 kA |
| (60 V DC) 10 kA | |
| Connecting Capacity UL/CSA | Busbar 18-8 AWG |
| Conductor 18-4 AWG | |
| Tightening Torque UL/CSA | 18 in·lb |
| Material Compliance | |
| RoHS Declaration | 9AKK107991A3220 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 28.02.2024 |
| REACH Declaration | 9AKK107492A1906 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20240821 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| SCIP | cb4a1e43-5e8e-4523-a11d-d56938299570 Germany |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Business |
| Environmental | |
| Ambient Air Temperature | Operation -40 ... +70 °C |
| Storage -55 ... +70 °C | |
| Degree of Protection | IP20 |
| IP40 | |
| Enclosure with Cover IP40 | |
| Pollution Degree | 3 |
| Environmental Conditions | 28 cycles |
| with 55 °C / 90-96 % | |
| and 25 °C / 95-100 % | |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 5g 5 ... 150 ... 5 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g 3 shocks 18 ms |
| Dimensions | |
| Width in Number of Modular Spacings | 1.0 |
| Product Net Width | 17.5 mm |
| Product Net Height | 88 mm |
| Product Net Depth / Length | 67.6 mm |
| Product Net Weight | 0.12 kg |
| Pole Net Weight | 0.124 kg |
| Built-In Depth (t2) | 69 mm |
| Engineering | |
| EPLAN Data | 9AAF617138_EPLAN |
| Ordering | |
| Package Level 1 Units | box 10 piece |
| Package Level 1 Gross Weight | 1.24 kg |
| E-Number (Finland) | 3216036 |
| E-Number (Norway) | 1641639 |
| E-Number (Sweden) | 2101051 |
| Certificates and Declarations | |
| CB Certificate | 2CDZ405000A1089 |
| 2CDZ405000A1093 | |
| CCA Certificate | 2CDZ405000A1090 |
| 2CDZ405000A1094 | |
| CCC Certificate | 2CDZ405000A1097 |
| 2CDZ405000A1098 | |
| CQC Certificate | 2CDZ405000A1097 |
| 2CDZ405000A1098 | |
| CSA Certificate | 2CDZ405000A1102 |
| Declaration of Conformity - CE | 9AKK107991A3220 |
| Declaration of Conformity - UKCA | 9AKK107992A8877 |
| DNV GL Certificate | 2CDZ405000A1155 |
| EAC Certificate | 2CDZ405000A1092 |
| 2CDZ405000A1096 | |
| NF Certificate | 2CDZ405000A1144 |
| RINA Certificate | 2CDZ405000A1194 |
| UL Certificate | 2CDZ405000A1101 |
| VDE Certificate | 2CDZ405000A1191 |
| 2CDZ405000A1195 | |
| Installation | |
| Instructions and Manuals | 2CDS207104P0002 |
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 |
| TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 | |
| Mounting Position | any |
| Popular Downloads | |
| Data Sheet, Technical Information | 9AKK107992A4964 |
| External Classifications and Standards | |
| ETIM 9 | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 10 | EC000042 - Miniature circuit breaker (MCB) |
| UNSPSC | 39121603 |
| eClass | V11.0 : 27141901 |
| IDEA Granular Category Code (IGCC) | 4897 >> Miniature circuit breakers |
| Object Classification Code | F |
| Standards | CSA 22.2 No. 235 |
| IEC/EN 60898-1 | |
| IEC/EN 60947-2 | |
| UL 1077 | |
| Certification Agency | CSA |
| IEC | |
| EN | |
| UL | |
| Standardization Body | EN |
| IEC | |
| UL | |
| CSA | |
