2CDS271445R0035 ABB Int. aut. S201MT-B3 1P 3A B 15kA
2CDS271445R0035
271445
ABB
1 Pcs.
Automation > Miniature circuit breaker (MCB)
Industrial
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An ABB 2CDS271445R0035 automatic circuit breaker offers dependable protection for electrical branch circuits by interrupting current flow during overload events. Installers rely on such DIN rail mounted circuit breakers to secure industrial control panels and wiring networks against fault currents. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 80.7 %
- ABB Site Meeting Group Waste To Landfill Target: No non-hazardous waste is sent to a landfill
- Extended Product Lifetime: Product Durability
- End Of Life Disassembling Instructions: 9AKK108468A3132
- Environmental Product Declaration - EPD: 9AKK108467A7832
- Dielectric Test Voltage: 50 / 60 Hz - 1 min 2 kV
- Rated Ultimate Short-Circuit Breaking Capacity (I cu ): (230 V) 15 kA
- Rated Service Short-Circuit Breaking Capacity (I cs ): 11.2 kA
- Energy Limiting Class: 3
- Mechanical Endurance: 20000 cycle
- Number of Protected Poles: 1
- Number of Poles: 1P
- Number of Modular Spacings per DIN Rail: 1
- Tightening Torque: 2.8 N·m
- Actuator Type: Toggle
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 80.7 % |
| ABB Site Meeting Group Waste To Landfill Target | No non-hazardous waste is sent to a landfill |
| Extended Product Lifetime | Product Durability |
| End Of Life Disassembling Instructions | 9AKK108468A3132 |
| Environmental Product Declaration - EPD | 9AKK108467A7832 |
| Technical | |
| Dielectric Test Voltage | 50 / 60 Hz - 1 min 2 kV |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (230 V) 15 kA |
| Rated Service Short-Circuit Breaking Capacity (Ics) | 11.2 kA |
| Energy Limiting Class | 3 |
| Mechanical Endurance | 20000 cycle |
| Number of Protected Poles | 1 |
| Number of Poles | 1P |
| Number of Modular Spacings per DIN Rail | 1 |
| Tightening Torque | 2.8 N·m |
| Actuator Type | Toggle |
| Screw Terminal Type | Failsafe Bi-directional Cylinder-lift Terminal |
| Actuator Marking | I / O |
| Actuator Material | Insulation Group II, Black, Sealable |
| Recommended Screw Driver | Pozidriv 2 |
| Accessories Available | Yes |
| Connecting Capacity | Busbar 10/10 mm² |
| Flexible with Ferrule 0.75 ... 16 mm² | |
| Flexible 0.75 ... 25 mm² | |
| Flexible 0.75 ... 25 mm² | |
| Rigid 0.75 ... 35 mm² | |
| Stranded 0.75 ... 35 mm² | |
| Installation Size | acc. to DIN 43880 3 |
| Terminal Type | Screw Terminals |
| Electrical | |
| Tripping Characteristic | B |
| Rated Voltage (Ur) | 440 V |
| Rated Operational Voltage | acc. to IEC 60898-1 230/400 V AC |
| acc. to IEC 60947-2 230 V AC | |
| Operational Voltage | Maximum (Incl. Tolerance) 253 V AC |
| Maximum (Incl. Tolerance) 66 V DC | |
| Minimum 12 V AC | |
| Minimum 12 V DC | |
| Rated Insulation Voltage (Ui) | acc. to IEC/EN 60664-1 440 V |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| at 2000 m 5 kV | |
| at Sea Level 6.2 kV | |
| Input Voltage Type | AC |
| Rated Current (In) | 3 A |
| Rated Short-Circuit Capacity | 10 kA |
| (230 V AC) 10 kA | |
| (400 V) 10 kA | |
| Rated Frequency (f) | 50 / 60 Hz |
| Power Loss | 1.3 W |
| Overvoltage Category | III |
| Design | |
| Housing Material | Insulation Group I, RAL 7035 |
| Material Compliance | |
| RoHS Declaration | 2CQB100288 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20220630 |
| REACH Declaration | 9AKK107492A1906 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| REACH Date | 20240821 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108468A3363 |
| SCIP | cf3c587b-f530-456e-834f-2f0e3c56c9e8 Germany |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| WEEE B2C / B2B | Business To Business |
| Environmental | |
| Ambient Air Temperature | Operation -40 ... +70 °C |
| Storage -40 ... +75 °C | |
| Degree of Protection | Enclosure with Cover IP20 |
| Pollution Degree | 3 |
| Environmental Conditions | 28 cycles |
| with 55 °C / 90-96 % | |
| and 25 °C / 95-100 % | |
| Resistance to Vibrations | 20 Cycles with Load 0.8 In: 5g 5 ... 150 ... 5 Hz |
| Resistance to Shock acc. to IEC 60068-2-27 | 25g 2 shocks 13 ms |
| Dimensions | |
| Width in Number of Modular Spacings | 1.0 |
| Product Net Width | 17.5 mm |
| Product Net Height | 88 mm |
| Product Net Depth / Length | 69 mm |
| Product Net Weight | 0.112 kg |
| Pole Net Weight | 0.115 kg |
| Built-In Depth (t2) | 69 mm |
| Ordering | |
| Package Level 1 Units | box 10 piece |
| Package Level 1 Gross Weight | 1.16 kg |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 2CQB100288 |
| Installation | |
| Instructions and Manuals | 2CDS207104P0002 |
| Mounting on DIN Rail | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 |
| TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 | |
| Mounting Position | any |
| Popular Downloads | |
| Data Sheet, Technical Information | 9AKK108467A7598 |
| External Classifications and Standards | |
| ETIM 9 | EC000042 - Miniature circuit breaker (MCB) |
| ETIM 10 | EC000042 - Miniature circuit breaker (MCB) |
| UNSPSC | 39121603 |
| eClass | V11.0 : 27141901 |
| IDEA Granular Category Code (IGCC) | 4897 >> Miniature circuit breakers |
| Object Classification Code | F |
| Standards | IEC/EN 60898-1 |
| IEC/EN 60947-2 | |
| UL 1077 | |
| CSA 22.2 No. 235 | |
| Certification Agency | EN |
| IEC | |
| Standardization Body | EN |
| IEC | |
