1STQ006248B0000 ABB IS2 Plac.mount 1800x800 for A1600,1ud
1STQ006248B0000
006248
ABB
1 Pcs.
Automation > Mounting plate for distribution board
Automation and Control enclosures
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A mounting plate provides a flat, secure surface for installing electrical devices, control gear, and DIN rail assemblies within industrial enclosures. The Abb 1STQ006248B0000 plac.mount 1800x800 for A1600,1ud supports organized internal layouts in control panel configurations.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Suitable For: Automation and Control Enclosures (System pro E control) - IS2
- Suitable for Product Class: Automation and Control Enclosures (System pro E control)
- Accessory Type: 2. Mounting Plates
- Product Type: 5B5B30B320
- Options Provided: 5. Mounting plates for structure W=1600mm
- Material: Galvanized Steel sheet
- RoHS Declaration: 9AKK108470A5607
- RoHS Date: 20250108
- REACH Declaration: 9AKK108470A5605
- REACH Information: False - does not contain substances > 0.1 mass percentage
- REACH Date: 20250108
- WEEE Category: Product Not in WEEE Scope
- Environmental Information: 1STC804013D0208
- Product Net Width: 746 mm
- Product Net Height: 1674 mm
- Product Net Depth / Length: 27 mm
More info
▲| Technical | |
|---|---|
| Suitable For | Automation and Control Enclosures (System pro E control) - IS2 |
| Suitable for Product Class | Automation and Control Enclosures (System pro E control) |
| Accessory Type | 2. Mounting Plates |
| Product Type | 5B5B30B320 |
| Options Provided | 5. Mounting plates for structure W=1600mm |
| Design | |
| Material | Galvanized Steel sheet |
| Material Compliance | |
| RoHS Declaration | 9AKK108470A5607 |
| RoHS Date | 20250108 |
| REACH Declaration | 9AKK108470A5605 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20250108 |
| WEEE Category | Product Not in WEEE Scope |
| Environmental | |
| Environmental Information | 1STC804013D0208 |
| Dimensions | |
| Product Net Width | 746 mm |
| Product Net Height | 1674 mm |
| Product Net Depth / Length | 27 mm |
| Product Net Weight | 28.2 kg |
| Reference Depth/Length | 300 mm |
| 400 mm | |
| 500 mm | |
| 600 mm | |
| 800 mm | |
| 1000 mm | |
| Reference Height | 1800 mm |
| Reference Width | 1600 mm |
| Ordering | |
| Package Level 1 Units | packet 1 piece |
| Package Level 1 Gross Weight | 28.2 kg |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 1STC860113 |
| Installation | |
| Instructions and Manuals | 1STM604121R0008 |
| Mounting Type | Kit |
| Pre assembled | |
| Popular Downloads | |
| Data Sheet, Technical Information | 1STC804013D0209 |
| External Classifications and Standards | |
| ETIM 9 | EC000213 - Mounting plate for distribution board |
| ETIM 10 | EC000213 - Mounting plate for distribution board |
| eClass | V11.1 : 27400639 |
| Object Classification Code | U |
