1STQ005573B0000 ABB Open Ceiling/Base IP30/40 A300 P1250
1STQ005573B0000
005573
ABB
1 Pcs.
Automation > Base/base element (switchgear cabinet)
Switchboards ArTu
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Abb 1STQ005573B0000 open ceiling and base assemblies provide crucial structural framing and top-bottom closure for high-capacity electrical distribution switchboards. These enclosure sections maintain required mechanical protection ratings while accommodating busbar frameworks in industrial power architectures.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Sub-Function 3: Base Complete
- Suitable For: Main Distribution Boards (System pro E power) - Top Busbar System Structure
- Suitable for Product Class: Main Distribution Boards (System pro E power)
- Product Type: 5P5P15P1510
- Door Type: Single
- Door Surface Finishing: Opaque
- Remarks: ETIM
- Material: Pickled steel sheet
- RAL Number: RAL 7035 - Light Grey
- RoHS Declaration: 1STE000077
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- RoHS Date: 20231024
- REACH Declaration: 1STE000078
- REACH Information: False - does not contain substances > 0.1 mass percentage
- REACH Date: 20241125
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
More info
▲| Technical | |
|---|---|
| Sub-Function 3 | Base Complete |
| Suitable For | Main Distribution Boards (System pro E power) - Top Busbar System Structure |
| Suitable for Product Class | Main Distribution Boards (System pro E power) |
| Product Type | 5P5P15P1510 |
| Door Type | Single |
| Door Surface Finishing | Opaque |
| Remarks | ETIM |
| Design | |
| Material | Pickled steel sheet |
| RAL Number | RAL 7035 - Light Grey |
| Material Compliance | |
| RoHS Declaration | 1STE000077 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20231024 |
| REACH Declaration | 1STE000078 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20241125 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| WEEE Category | Product Not in WEEE Scope |
| WEEE B2C / B2B | Business To Business |
| Environmental | |
| Environmental Information | 1STC803005D0208 |
| 9AKK108467A6707 | |
| Dimensions | |
| Product Net Width | 0.001 mm |
| Product Net Height | 20 mm |
| Product Net Depth / Length | 0.001 mm |
| Product Net Weight | 0.001 kg |
| Engineering | |
| Building Information Modeling – BIM | 1STC860077 |
| Ordering | |
| Package Level 1 Units | 1 piece |
| Package Level 1 Gross Weight | 4.3 kg |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 1STC860111 |
| Installation | |
| Instructions and Manuals | 1STS100367R0001 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1STC803005D0208 |
| External Classifications and Standards | |
| ETIM 9 | EC000721 - Base/base element (enclosure/cabinet) |
| ETIM 10 | EC000721 - Base/base element (enclosure/cabinet) |
| eClass | V11.1 : 27182003 |
