1SFA899011R1132 ABB Thyristor PSTM-132/18
1SFA899011R1132
899011
ABB
1 Pcs.
Automation > Accessories/spare parts for low-voltage switch technology
Spare parts Power Switches ABB
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Abb 1SFA899011R1132 ABB Thyristor PSTM-132/18 acts as a solid-state semiconductor switching device used to regulate high AC currents in industrial power control circuits. Thyristors are widely deployed in soft starters and power regulation equipment for smooth phase control and motor starting.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85413000
- Data Sheet, Technical Information: 1SFC132013C0201
- Instructions and Manuals: 5309705-1
- CAD Dimensional Drawing: 2CDC001079B0201
- Wiring Diagram: 1SFC132041M001
- Product Net Width: 33 mm
- Product Net Height: 30 mm
- Product Net Depth / Length: 93 mm
- Product Net Weight: 0.122 kg
- Rated Operational Voltage: 380 V AC
- Product Main Type: PSTM
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- REACH Declaration: 2CMT2022-006481
- RoHS Declaration: 2CMT2022-006500
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85413000 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1SFC132013C0201 |
| Instructions and Manuals | 5309705-1 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Wiring Diagram | 1SFC132041M001 |
| Dimensions | |
| Product Net Width | 33 mm |
| Product Net Height | 30 mm |
| Product Net Depth / Length | 93 mm |
| Product Net Weight | 0.122 kg |
| Technical | |
| Rated Operational Voltage | 380 V AC |
| Main Circuit 690 V | |
| Product Main Type | PSTM |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2022-006481 |
| RoHS Declaration | 2CMT2022-006500 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006524 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | Product Not in WEEE Scope |
| Container Information | |
| Package Level 1 Width | 53 mm |
| Package Level 1 Depth / Length | 113 mm |
| Package Level 1 Height | 50 mm |
| Package Level 1 Gross Weight | 0.172 kg |
| Package Level 1 EAN | 7320500218969 |
| Package Level 1 Units | box 1 piece |
| External Classifications and Standards | |
| Object Classification Code | Q |
| ETIM 7 | EC000249 - Protection switch disconnector housing |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| ETIM 9 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| eClass | V11.0 : 27371392 |
| UNSPSC | 32111700 |
