1SDA104611R1 ABB E6.2H/E9 6300 Ekip Dip LSIG 3p FHR
1SDA104611R1
104611
ABB
1 Pcs.
E6.2H/E9 6300 Ekip Dip LSIG 3p FHR
Automation > Power circuit-breaker for trafo/generator/installation protection
Rack "Megamax-Emax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2364 |
| Environmental Product Declaration - EPD | 9AKK108471A0821 |
| Extended Product Lifetime | Lifetime Extension Services are Offered |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | a0008e56-9261-4450-97d7-2f11f7dace24 Italy |
| Simplified SCIP | f5ff2416-b00a-45a6-a750-5b456dd1b7a7 Germany |
| 1184ea6f-84e8-43bd-ac8a-308cc8e522ce Bulgaria | |
| babdecae-2298-4718-b836-fa3df403a91f Denmark | |
| c9aff936-26ad-463e-b311-9c3437cf254b Sweden | |
| 9c096ba3-6ec6-47ad-8ff5-891fece53710 Poland | |
| 81e83a9c-6496-4556-8680-5f4dc32a0737 France | |
| 8c3c6128-25b8-4fa2-960b-8967318cf19e Germany | |
| 4d9268c7-eba6-4e45-94cf-2fc7906f7abe Poland | |
| b650e42a-f2d3-4a0d-a73b-7621d513a20d Finland | |
| 88ba463a-13a4-4627-8a23-198c43195d86 Sweden | |
| c58fba9f-5653-4c7e-b430-0af176476531 Croatia | |
| 6a507891-da01-45cc-afc8-6ab814c29830 Norway | |
| 9d7587b5-37cf-40af-b81a-b9bc4011cfd4 Belgium | |
| 5f3f05e1-9d57-4a72-80e1-ed557f31c283 Belgium | |
| 44c6ad48-7310-4d15-9b1c-950f08de5aa0 Germany | |
| 654d985f-5698-4e27-8016-67b1caaefb3f Czech Republic | |
| 017189d1-5683-4c78-8a7f-19d2ff31c9ec Germany | |
| e109a13f-b166-45b7-9d5c-79039c8fc771 Hungary | |
| b503b69c-4071-4a74-a2d0-49b271ad5644 Spain | |
| c2492333-7a77-466f-8640-29e887ded0cf France | |
| 25162f2f-6da8-4b29-92cb-506e78967a73 Netherlands | |
| 51b4485b-b7e6-4129-9da1-34f9f48412c8 Poland | |
| 5881c445-509a-4ac1-b357-bb2ca7ff9961 Germany | |
| c15fcccc-3f17-433e-a073-5fbde6cd1fe0 Portugal | |
| 32724a05-5b40-4b50-a02a-70f91df57208 Greece | |
| c43c54e1-c21e-4909-95db-45076cf71757 Hungary | |
| 0dbd6424-9129-4d13-8a88-89e2d589b319 Estonia | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| Order Code US and Canada | 96HYETBC000A000000XX |
| EAN | 8056221026642 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 762 mm |
| Product Net Height | 371 mm |
| Product Net Depth / Length | 270 mm |
| Product Net Weight | 109 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 515 mm |
| Package Level 1 Height | 610 mm |
| Package Level 1 Depth / Length | 1000 mm |
| Package Level 1 Gross Weight | 129 kg |
| Package Level 1 EAN | 8056221026642 |
| Additional Information | |
| Product Main Type | SACE Emax 2 |
| Product Name | Air Circuit Breaker |
| Product Type | Air Circuit Breaker |
| Version | F |
| Technical | |
| Current Type | AC |
| Electrical Durability | Ue = 900 V 1000 cycle |
| 10 cycles per hour | |
| Mechanical Durability | 12000 cycle |
| 60 cycles per hour | |
| Number of Poles | 3P |
| Power Loss | 767 W |
| Rated Current (In) | 6300 A |
| Rated Impulse Withstand Voltage (Uimp) | acc. to IEC 60947-2 12 kV |
| Rated Insulation Voltage (Ui) | AC 1000 V |
| Rated Operational Voltage | 900 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (800 V AC) 90 kA |
| (900 V AC) 75 kA | |
| Rated Short-time Withstand Current Low Voltage (Icw) | for 1 s 75 kA |
| for 3 s 66 kA | |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (800 V AC) 90 kA |
| (900 V AC) 75 kA | |
| Rated Uninterrupted Current (Iu) | 6300 A |
| Rated Voltage (Ur) | 900 V |
| Release | Ekip Dip LSIG |
| Release Type | EL |
| Remarks | E9 |
| Short-Circuit Performance Level | H |
| Standards | IEC |
| Sub-type | E6.2 |
| Suitable for IT Networks | No |
| Terminal Connection Type | Rear flat Horizontal |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC200023D0209 |
| Declaration of Conformity - CE | 9AKK107680A4890 |
| Instructions and Manuals | 1SDH001000R0002 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
