1SDA100820R1 ABB Ekip Dip LSIG In 800 XT6 4p
1SDA100820R1
100820
ABB
1 Pcs.
Ekip Dip LSIG In=800 XT6 4p
Automation > Shunt release (for power circuit breaker)
Molded case "Isomax-Tmax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
ABB 1SDA100820R1 Ekip Dip LSIG In 800 XT6 4p is an electronic trip unit engineered to deliver multi-parameter protection including overload, short-circuit, instantaneous, and ground-fault tripping. These units provide robust safeguarding for high-ampere multi-pole power distribution switchgear.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- SCIP: 61741f6e-a79f-439e-b358-1b58263c4467 China
- Simplified SCIP: 9c9e3ad7-88a6-4ba9-bb6f-b612b251c4d0 Spain
- Environmental Information: 9AKK108467A6707
- EAN: 8056221008747
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85389099
- Product Net Weight: 1.6 kg
- Package Level 1 Units: box 1 piece
- Package Level 1 Width: 120 mm
- Package Level 1 Height: 160 mm
- Package Level 1 Depth / Length: 190 mm
More info
