1SDA100732R1 ABB XT6N 800 Ekip Dip LS/I In 800 4p F F
1SDA100732R1
100732
ABB
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An ABB circuit breaker, catalog number 1SDA100732R1, functions as a protective interrupter designed to disconnect electrical power automatically during hazardous overcurrent situations. Heavy-duty switchgear panels utilize such components to maintain safety and prevent equipment damage across industrial sites.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- ABB Site Meeting Group Waste To Landfill Target: UL 2799 Zero Waste To Landfill Validation available
- End Of Life Disassembling Instructions: 9AKK108468A2356
- Environmental Product Declaration - EPD: 9AKK108468A9752
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 60 %
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- SCIP: e379d012-746e-483c-80bf-0e82d733c995 Italy
- Simplified SCIP: a833adb8-7776-48cb-ae6d-cbe2dd6226fa Germany
- Environmental Information: 9AKK108467A6707
- Order Code US and Canada: XT6NE4800EFF000XXX
- E-Number (Finland): 3641874
- E-Number (Norway): 4380577
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2356 |
| Environmental Product Declaration - EPD | 9AKK108468A9752 |
| 9AKK108468A2295 | |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 60 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | e379d012-746e-483c-80bf-0e82d733c995 Italy |
| Simplified SCIP | a833adb8-7776-48cb-ae6d-cbe2dd6226fa Germany |
| dad18599-fb02-4756-a040-409c978250c0 Czech Republic | |
| 67171abd-5a17-4c96-b8dc-b99419aab2d8 Poland | |
| 0036f7a7-c643-4a26-9045-0869715c82b5 Croatia | |
| e7d55f7f-1ee1-49d3-a4f8-20acfd1ecddf Poland | |
| 91409b6e-d025-40b9-8015-a8926511c6df Finland | |
| fb1734ad-9859-4673-b6b4-87742ece484b Belgium | |
| c61fc6b7-3963-4114-8d89-56d7ba1f239f Germany | |
| 55b97f01-94ba-4e47-925b-17d2c93da51c Denmark | |
| 921236cc-e754-425d-ba28-360d7ad944c3 Germany | |
| 31221b9b-3a3b-4657-9c64-07a971dd7820 Estonia | |
| 4c307981-1212-4d01-8812-5d7605dc49ac Hungary | |
| 939463d1-7859-4f5a-be8a-d397f8e42116 Norway | |
| c26353a6-cf5c-4945-952f-dce0d0557d02 Netherlands | |
| a033f770-fd18-400d-abd0-334c4d916b90 Germany | |
| b798dcca-8da0-4169-a559-30b8b946e49d Greece | |
| a52cbd21-57dd-4b20-9895-21f9365aad88 Portugal | |
| 6d59bd6c-9905-4f60-ad85-947b65e70ab0 Bulgaria | |
| 9e25b435-b289-4e93-b5be-d214578d0042 Sweden | |
| 437d4e10-1e41-478a-81ef-bf5fb29e1bb1 Poland | |
| d25fc0e8-c3d8-4da7-b9b5-364508a1cf59 France | |
| 0196c414-8bec-4ec5-a9c3-040dbe8c3251 Sweden | |
| 6ca885cd-4536-4cd9-86e9-32c609df1b6d Hungary | |
| 55c42dce-0a3b-4a34-8105-230ba357b9f3 Germany | |
| 69e00e78-b14e-4428-8a06-89ccc0c0adcb France | |
| 5e099680-ac60-4ae2-9953-81256bd94ca8 Spain | |
| 9142d482-3c63-4b9d-b74e-4ee93a08f389 Belgium | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| Order Code US and Canada | XT6NE4800EFF000XXX |
| E-Number (Finland) | 3641874 |
| E-Number (Norway) | 4380577 |
| EAN | 8056221003575 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 280 mm |
| Product Net Height | 268 mm |
| Product Net Depth / Length | 103.5 mm |
| Product Net Weight | 12 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 305 mm |
| Package Level 1 Height | 285 mm |
| Package Level 1 Depth / Length | 370 mm |
| Package Level 1 Gross Weight | 14 kg |
| Package Level 1 EAN | 8056221003575 |
| Additional Information | |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| CAD Dimensional Drawing | 1SDH002065A1214 |
| 1SDH002065A1245 | |
| Technical | |
| Current Type | AC |
| Electrical Durability | 5000 cycle |
| 60 cycles per hour | |
| Mechanical Durability | 20000 cycle |
| 120 cycles per hour | |
| Number of Poles | 4P |
| Order Multiple | 1 piece |
| Power Loss | 53.4 W |
| Rated Current (In) | 800 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 70 kA |
| (230 V AC) 70 kA | |
| (240 V AC) 70 kA | |
| (380 V AC) 36 kA | |
| (415 V AC) 36 kA | |
| (440 V AC) 30 kA | |
| (500 V AC) 25 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 20 kA | |
| Rated Short-time Withstand Current Low Voltage (Icw) | 10 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 70 kA |
| (230 V AC) 70 kA | |
| (240 V AC) 70 kA | |
| (380 V AC) 36 kA | |
| (415 V AC) 36 kA | |
| (440 V AC) 30 kA | |
| (500 V AC) 25 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 20 kA | |
| (250 V DC) 2 Poles in Series 36 kA | |
| (500 V DC) 2 Poles in Series 20 kA | |
| (750 V DC) 3 Poles in Series 18 kA | |
| Rated Uninterrupted Current (Iu) | 800 A |
| Release | Ekip Dip LS/I |
| Release Type | EL |
| Short-Circuit Performance Level | N |
| Standards | IEC60947-2 |
| Sub-type | XT6 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK107680A2825 |
| Mechanical Drawings | 1SDH002012A1101 |
| Wiring Diagram | 1SDM000005A1001 |
| Instructions and Manuals | 1SDH002012A1001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
