1SDA100721R1 ABB XT6N 800 Ekip Dip LSI In 800 3p F F
1SDA100721R1
100721
ABB
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The 1SDA100721R1 ABB XT6N 800 Ekip Dip LSI In 800 3p F F serves as a molded case circuit breaker designed to handle high-current electrical distribution protection. Such devices are frequently utilized in commercial and industrial electrical architecture to interrupt fault currents and ensure operational safety. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- ABB Site Meeting Group Waste To Landfill Target: UL 2799 Zero Waste To Landfill Validation available
- End Of Life Disassembling Instructions: 9AKK108468A2356
- Environmental Product Declaration - EPD: 9AKK108468A9752
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 60 %
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- SCIP: dda0a32a-7df0-4dfb-b115-0ae691e6537c China
- Simplified SCIP: 4737713f-7ccb-4a89-9c4a-ac647c6a492b Croatia
- Environmental Information: 9AKK108467A6707
- Order Code US and Canada: XT6NE3800FFF000XXX
- E-Number (Finland): 3641877
- E-Number (Norway): 4380515
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2356 |
| Environmental Product Declaration - EPD | 9AKK108468A9752 |
| 9AKK108468A2295 | |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 60 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | dda0a32a-7df0-4dfb-b115-0ae691e6537c China |
| Simplified SCIP | 4737713f-7ccb-4a89-9c4a-ac647c6a492b Croatia |
| c022609d-dc03-473f-8081-daf46a433151 Hungary | |
| b2c7bcb8-d56f-4caa-a3ff-064eac6df335 Finland | |
| 6419e92c-6297-4ba2-a0a5-ec0db7933c3c Czech Republic | |
| 03220399-092b-493d-99ca-3a9cb3b23284 Poland | |
| 4784ecdb-fbf5-44dc-8f72-f0185a4629bc Poland | |
| 30c1def4-2315-4705-8783-84130462ed48 Sweden | |
| 5fb6b5ad-93ff-4d03-a547-fc2b18cb7dfa Portugal | |
| 16f468a9-1812-416e-a90d-48a7dbea513f Bulgaria | |
| 6611f7ac-4c9f-46bb-9c12-bb492e1d85f8 Germany | |
| 8ec31de0-7303-471d-bdc8-21326f01c9a1 Poland | |
| f7abf554-df94-4ca4-97ae-b53621d47d82 France | |
| 5decb126-e525-4052-b72b-0fcaecd343fc Norway | |
| 495b3f31-0eed-42d4-aff9-d48c3c6c4cd1 Germany | |
| bab7daa4-6e66-4e54-96a7-a0df98d0f178 France | |
| 7058e452-c59b-4a6d-9f12-959ca1a14d8b Sweden | |
| bdbb53fb-bb8f-4bb2-b599-3f838d679b82 Netherlands | |
| 38a7c82a-555e-47ee-bf4a-ab50392a2046 Germany | |
| 3ab10e16-b46b-4aba-85d7-fdeabef9f21b Greece | |
| 1c12a648-c7ee-4459-ac6e-755e14c614d3 Hungary | |
| 2716a03b-b0f3-4231-b670-2782d8ae5e64 Estonia | |
| 9339b1ed-22c1-4a7e-9206-55d6da324d21 Belgium | |
| e4ad95e4-3deb-4363-bb1a-74cbf2031f5c Belgium | |
| f7de5bd0-9b4c-4650-bc52-8657969bbc41 Spain | |
| 46b95a08-dba4-489a-a46f-ef26656739a0 Germany | |
| 3b07f12b-b446-4377-8cb3-1bc6026b3660 Denmark | |
| d8a69e90-a0fb-4909-8fe6-95f042d9dc4b Germany | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| Order Code US and Canada | XT6NE3800FFF000XXX |
| E-Number (Finland) | 3641877 |
| E-Number (Norway) | 4380515 |
| EAN | 8056221007979 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 210 mm |
| Product Net Height | 268 mm |
| Product Net Depth / Length | 103.5 mm |
| Product Net Weight | 9.5 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 305 mm |
| Package Level 1 Height | 285 mm |
| Package Level 1 Depth / Length | 370 mm |
| Package Level 1 Gross Weight | 11 kg |
| Package Level 1 EAN | 8056221007979 |
| Additional Information | |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| CAD Dimensional Drawing | 1SDH002065A1190 |
| 1SDH002065A1245 | |
| Technical | |
| Current Type | AC |
| Electrical Durability | 5000 cycle |
| 60 cycles per hour | |
| Mechanical Durability | 20000 cycle |
| 120 cycles per hour | |
| Number of Poles | 3P |
| Order Multiple | 1 piece |
| Power Loss | 53.4 W |
| Rated Current (In) | 800 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 70 kA |
| (230 V AC) 70 kA | |
| (240 V AC) 70 kA | |
| (380 V AC) 36 kA | |
| (415 V AC) 36 kA | |
| (440 V AC) 30 kA | |
| (500 V AC) 25 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 20 kA | |
| Rated Short-time Withstand Current Low Voltage (Icw) | 10 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 70 kA |
| (230 V AC) 70 kA | |
| (240 V AC) 70 kA | |
| (380 V AC) 36 kA | |
| (415 V AC) 36 kA | |
| (440 V AC) 30 kA | |
| (500 V AC) 25 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 20 kA | |
| (250 V DC) 2 Poles in Series 36 kA | |
| (500 V DC) 2 Poles in Series 20 kA | |
| (750 V DC) 3 Poles in Series 18 kA | |
| Rated Uninterrupted Current (Iu) | 800 A |
| Release | Ekip Dip LSI |
| Release Type | EL |
| Short-Circuit Performance Level | N |
| Standards | IEC60947-2 |
| Sub-type | XT6 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 2CDC210017C0101 |
| 1SDC210100D0206 | |
| 1SXF210033C2001 | |
| 1SDC210099D0206 | |
| 1SXF210034C2001 | |
| Declaration of Conformity - CE | 9AKK107680A2825 |
| Mechanical Drawings | 1SDH002012A1101 |
| Wiring Diagram | 1SDM000005A1001 |
| Instructions and Manuals | 1SDH002012A1001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
