1SDA100656R1 ABB TMA 400-4000 XT5 4p InN 100%In
1SDA100656R1
100656
ABB
1 Pcs.
TMA 400-4000 XT5 4p InN=100%In
Automation > Shunt release (for power circuit breaker)
Molded case "Isomax-Tmax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Abb 1SDA100656R1 TMA 400-4000 XT5 4p InN 100%In is a thermal-magnetic release trip unit used to protect electrical distribution lines from both sustained overloads and sudden short-circuit events. Such internal breaker components provide reliable thermal and magnetic tripping behavior in industrial applications.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- SCIP: cd3e4f8c-666f-403a-a36d-3eb7e5a3560d Italy
- Simplified SCIP: fe9b42bd-c53a-42f9-a282-7d16fb7c1df6 Finland
- Environmental Information: 9AKK108467A6707
- E-Number (Norway): 4380470
- EAN: 8056221007320
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85389099
- Product Net Weight: 1.05 kg
- Package Level 1 Units: box 1 piece
- Package Level 1 Width: 120 mm
- Package Level 1 Height: 180 mm
