ABB 1SDA100535R1 1SDA100535R1 ABB XT5H 400 Ekip Dip LSIG In 320 4p F F View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA100535R1 ABB XT5H 400 Ekip Dip LSIG In 320 4p F F

1SDA100535R1

100535

ABB

1 Pcs.

XT5H 400 Ekip Dip LSIG In=320 4p F F

Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
ABB EcoSolutions
ABB EcoSolutionsYes
ABB Site Meeting Group Waste To Landfill TargetUL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions9AKK108468A2354
Environmental Product Declaration - EPD9AKK108468A1899
9AKK108468A9748
Extended Product LifetimeProduct Modularity
Recyclability Rate of the Product acc. to EN45555Design for Closing Resource Loops - Standard EN45555 - 59.6 %
Material Compliance
REACH Declaration9AKK108466A1425
RoHS Declaration9AKK108466A1424
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Toxic Substances Control Act - TSCA9AKK108467A8326
SCIP06244d5c-f80b-4e5b-8fe3-909a332c5f67 China
Simplified SCIP20a6c1d5-0c3c-41fe-adfd-98c84dc4f777 Portugal
74cc86f9-a64c-42fa-be64-32b13e54c8ca Hungary
305b82a0-68b5-4f64-a54d-fd2eb9de95f2 Spain
6b5cc9ba-bda0-4b8a-8963-99a6b1153510 Germany
d16095ae-6a34-414e-a19d-d221d1e833c1 Hungary
33712df6-abea-41ff-b426-245033d7eb89 Sweden
1d42d133-94a0-4bc1-86bc-57cb9cfa11ec Germany
a57507fc-3f06-421c-81f5-bf5c8fb60b54 France
6c0e589a-099f-4c49-8535-c5743d3e8b06 Poland
7e1187a6-d260-4118-8d91-9ebd52dea7ee Bulgaria
4df116d0-ef34-474e-8919-f10aa3ff7d78 Poland
2011b729-f34e-4312-ac14-c52e49755d63 Finland
d3e8b529-a39c-4956-8013-aad3922e39b9 Czech Republic
5a74d84b-133b-4645-8713-0ce2cafdb2b7 Croatia
3e9a244d-7fac-44f0-a3c2-d822698aef25 Norway
6c1a9ed6-09da-4850-a0b5-d193fc54cc1d Sweden
b5aafe60-4136-47ff-8c32-d5479c437400 Germany
035c03d7-7a9e-4458-801f-e47f4d073e17 Denmark
b9c6e6fb-85a9-4f84-a99a-bd3a6f93029d Germany
f36f0fcd-a5e6-449e-a914-f6115c2eb1ce Estonia
757da8cd-cb72-4a36-acd4-d9f0054471bf Belgium
e6bce5da-badb-48d9-ba8f-5aca88a56796 Greece
ad1eb650-726b-4fb7-86df-b9e23854218a Poland
5e712f34-9199-4ef3-ad17-f9986e50b2d0 Netherlands
3f493aeb-3e7f-4aa1-aded-8b9a16267770 France
400cd9c6-e795-4aee-8f63-633eae5328ed Belgium
fc196055-d7ab-4a1e-b939-9d8aa714e492 Germany
Environmental
Environmental Information9AKK108467A6707
Ordering
Order Code US and CanadaXT5HE432AGFF000XXX
EAN8056221006118
Minimum Order Quantity1 piece
Customs Tariff Number85362090
Dimensions
Product Net Width186 mm
Product Net Height205 mm
Product Net Depth / Length103.5 mm
Product Net Weight6.4 kg
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width250 mm
Package Level 1 Height245 mm
Package Level 1 Depth / Length285 mm
Package Level 1 Gross Weight6.888 kg
Package Level 1 EAN8056221006118
Additional Information
Circuit Breaker Type to be AssociatedPower Distribution
Product Main TypeSACE Tmax XT
Product NameMoulded Case Circuit Breaker
Product TypeAutomatic Circuit Breaker
VersionF
CAD Dimensional Drawing1SDH002065A1183
1SDH002065A1131
Technical
Current TypeAC
Electrical Durability7000 cycle
60 cycles per hour
Mechanical Durability20000 cycle
120 cycles per hour
Number of Poles4P
Order Multiple1 piece
Power Loss11.6 W
Rated Current (In)320 A
Rated Impulse Withstand Voltage (Uimp)8 kV
Rated Insulation Voltage (Ui)1000 V
Rated Operational Voltage690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics)(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 50 kA
(690 V AC) 40 kA
Rated Short-time Withstand Current Low Voltage (Icw)5 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu)(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 50 kA
(690 V AC) 40 kA
Rated Uninterrupted Current (Iu)400 A
ReleaseEkip Dip LSIG
Release TypeEL
Short-Circuit Performance LevelH
StandardsIEC60947-2
Sub-typeXT5
Terminal Connection TypeFront
Certificates and Declarations
Data Sheet, Technical Information1SDC210100D0206
1SDC210099D0206
Declaration of Conformity - CE9AKK107680A2824
EU Data Act Compliance Declaration1SDH002560A1001
Mechanical Drawings1SDH002011A1101
Wiring Diagram1SDM000005A1001
Instructions and Manuals1SDH002011A1001
External Classifications and Standards
ETIM 9EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification CodeQ
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
eClassV11.1 : 27370409

ETIM for 1SDA100535R1 Low-voltage industrial controls and switchgear (EC000228)
Feature Name Feature Value
Rated permanent current Iu (EF001389) 320 A
Rated voltage (EF003977) 690 V
Overload release current setting (EF002336) 128.0 A
Adjustment range short-term delayed short-circuit release (EF007129) 320 A
Adjustment range undelayed short-circuit release (EF007131) 320 A
Integrated earth fault protection (EF007296) No
Type of electrical connection of main circuit (EF006819) Bolt connection
Device construction (EF008240) Built-in device fixed built-in technique
Suitable for DIN rail (top hat rail) mounting (EF007250) No
DIN rail (top hat rail) mounting optional (EF008904) No
Number of auxiliary contacts as normally closed contact (EF001377) 0
Number of auxiliary contacts as normally open contact (EF001376) 0
Number of auxiliary contacts as change-over contact (EF003531) 0
With switched-off indicator (EF007006) No
With integrated under voltage release (EF001390) No
Number of poles (EF001391) 4
Position of connection for main current circuit (EF006671) Front
Type of control element (EF006976) Toggle
Complete device with protection unit (EF008906) Yes
Motor drive integrated (EF006697) No
Motor drive optional (EF007386) Yes
Degree of protection (IP) (EF005474) IP20
