ABB 1SDA100533R1 1SDA100533R1 ABB XT5H 630 Ekip Dip LSI In 630 4p F F View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA100533R1 ABB XT5H 630 Ekip Dip LSI In 630 4p F F

1SDA100533R1

100533

ABB

1 Pcs.

XT5H 630 Ekip Dip LSI In=630 4p F F

Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
ABB EcoSolutions
ABB EcoSolutionsYes
ABB Site Meeting Group Waste To Landfill TargetUL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions9AKK108468A2354
Environmental Product Declaration - EPD9AKK108468A1899
9AKK108468A9748
Extended Product LifetimeProduct Modularity
Recyclability Rate of the Product acc. to EN45555Design for Closing Resource Loops - Standard EN45555 - 59.6 %
Material Compliance
REACH Declaration9AKK108466A1425
RoHS Declaration9AKK108466A1424
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Toxic Substances Control Act - TSCA9AKK108467A8326
SCIPba0ac887-7218-497b-85a8-2413c38f851e Italy
Simplified SCIPe78b09cb-459e-4d1a-be52-c804736f8a82 Spain
b5f5ac64-ffce-4fe2-81e2-314de886d98a Germany
f3319fa6-bcfd-4988-a998-82a7c48554ee Hungary
3709f25c-726b-4caf-aa7b-ce1b580b3957 Netherlands
900222b7-9fd6-4eb3-aff5-c21fa812863d Poland
308685f0-ef57-44dd-b37a-b9f51271561c Czech Republic
7df862a3-a45e-4828-a5ab-d015d8b3e383 Germany
786b20d6-df6c-4dfb-8af2-8f110f44bbe6 Croatia
bc0bc5a8-3cca-4c93-8adc-627106bbe706 Denmark
be123d4c-63a5-4794-ba23-6e7d21f593d5 Germany
83915913-5458-4fb0-8dbe-cf07b2fc767c Belgium
caa425b5-aebb-4e23-bd1c-ef0a87507f2f Poland
9d2234bf-13ab-482b-a2de-fef93b23ad4d Germany
013ba8f6-4bc0-469f-9c8c-971a19146d0d Germany
2b93712f-dceb-41af-82a5-aca7d025b8f3 Sweden
d5f00957-2452-4473-a5e1-869a179fc163 France
5882304d-14ec-4ddb-bced-0a4afe05d155 Poland
21d66e5f-ece7-417e-a9e3-0a6c2ce1e9bd Finland
544e5fa9-657f-4969-a103-bb8d98c3e9b3 Norway
af19927f-1272-4d9d-a299-8530fe7dd0f4 Estonia
cb53c5de-b66e-4164-8b1a-88c8b5c8cfea Hungary
44d3a0d3-930d-4b1f-85bc-e70418639786 Sweden
eff05719-e6df-4485-a764-cdf73943965b Portugal
e3085f1b-4eb1-49c1-be86-5d39d467089a Bulgaria
9383e75f-74af-4100-a1ce-8b61c3636298 Greece
4501582b-84bf-4c92-8eaf-101f687c8b3e France
bb43f4eb-e496-4fe1-af13-af5d780c2dd2 Belgium
Environmental
Environmental Information9AKK108467A6707
Ordering
Order Code US and CanadaXT5HE463BFFF000XXX
E-Number (Norway)4380441
EAN8056221006095
Minimum Order Quantity1 piece
Customs Tariff Number85362090
Dimensions
Product Net Width186 mm
Product Net Height205 mm
Product Net Depth / Length103.5 mm
Product Net Weight6.4 kg
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width250 mm
Package Level 1 Height245 mm
Package Level 1 Depth / Length285 mm
Package Level 1 Gross Weight6.888 kg
Package Level 1 EAN8056221006095
Additional Information
Circuit Breaker Type to be AssociatedPower Distribution
Product Main TypeSACE Tmax XT
Product NameMoulded Case Circuit Breaker
Product TypeAutomatic Circuit Breaker
VersionF
CAD Dimensional Drawing1SDH002065A1183
1SDH002065A1131
Technical
Current TypeAC
Electrical Durability5000 cycle
60 cycles per hour
Mechanical Durability20000 cycle
120 cycles per hour
Number of Poles4P
Order Multiple1 piece
Power Loss45 W
Rated Current (In)630 A
Rated Impulse Withstand Voltage (Uimp)8 kV
Rated Insulation Voltage (Ui)1000 V
Rated Operational Voltage690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics)(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 50 kA
(690 V AC) 30 kA
(250 V DC) 2 Poles in Series 10 kA
(500 V DC) 2 Poles in Series 10 kA
Rated Short-time Withstand Current Low Voltage (Icw)6 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu)(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 50 kA
(690 V AC) 40 kA
Rated Uninterrupted Current (Iu)630 A
ReleaseEkip Dip LSI
Release TypeEL
Short-Circuit Performance LevelH
StandardsIEC60947-2
Sub-typeXT5
Terminal Connection TypeFront
Certificates and Declarations
Data Sheet, Technical Information1SDC210100D0206
1SDC210099D0206
Declaration of Conformity - CE9AKK107680A2824
EU Data Act Compliance Declaration1SDH002560A1001
Mechanical Drawings1SDH002011A1101
Wiring Diagram1SDM000005A1001
Instructions and Manuals1SDH002011A1001
External Classifications and Standards
ETIM 9EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification CodeQ
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
eClassV11.1 : 27370409
