1SDA100532R1 ABB XT5H 400 Ekip Dip LSI In 400 4p F F
1SDA100532R1
100532
ABB
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
ABB XT5H 400 Ekip Dip LSI In 400 4p F F is a molded case circuit breaker built to provide reliable circuit protection and fault interruption in demanding electrical architectures. Such components are typically installed within industrial control panels to protect distribution networks and downstream machinery from overcurrent scenarios.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- ABB Site Meeting Group Waste To Landfill Target: UL 2799 Zero Waste To Landfill Validation available
- End Of Life Disassembling Instructions: 9AKK108468A2354
- Environmental Product Declaration - EPD: 9AKK108468A1899
- Extended Product Lifetime: Product Modularity
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 59.6 %
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- SCIP: 4b831370-5f3d-412c-a2be-c9d15fc20b59 Italy
- Simplified SCIP: 42e8b486-109f-48b4-b212-afb615aea800 Czech Republic
- Environmental Information: 9AKK108467A6707
- Order Code US and Canada: XT5HE440AFFF000XXX
- E-Number (Norway): 4380440
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2354 |
| Environmental Product Declaration - EPD | 9AKK108468A1899 |
| 9AKK108468A9748 | |
| Extended Product Lifetime | Product Modularity |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 59.6 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | 4b831370-5f3d-412c-a2be-c9d15fc20b59 Italy |
| Simplified SCIP | 42e8b486-109f-48b4-b212-afb615aea800 Czech Republic |
| 7a6ad1a5-b3ec-4e0d-ac9a-25d42fe7a192 Netherlands | |
| 65f195e1-6da4-4512-8909-26fda0bead9f Poland | |
| 6b8846b9-9b13-48ef-9694-8fb5b4d42f68 Poland | |
| 2e7f3aa2-efad-4490-8b1d-3b900ff51d7e Belgium | |
| 830c6802-a09f-459b-9232-51fe429942df Denmark | |
| b89c6e1a-9f05-462a-93c1-78c94ad5bf46 Germany | |
| bcd3aad7-9338-47a2-9bf4-348c62b2bb2b Croatia | |
| 8c0c7581-cfc7-43c0-a6dd-90433a3729a5 Germany | |
| 67b1c3b6-fcfc-41bc-8c97-eeac032d3be9 Germany | |
| 62687ee4-051e-4398-8621-8d92ec2b2c0a Germany | |
| a9f9c79c-2c19-4a0c-9d3f-21b614799a4d France | |
| 4105eee4-af03-43dd-b6ed-524d999a4b48 Sweden | |
| 5a3e1beb-66ce-4ad8-beb5-a211d1dbd67d Estonia | |
| 22df3aca-cd8e-4fb3-a692-7e34cc0c12dc Hungary | |
| e58cdfa6-3dce-4a92-bcfc-4e0f177c382f Greece | |
| 821729bd-155e-4764-9b27-2e9dd5b13416 Bulgaria | |
| a1c2c61f-c85b-43a5-8398-6faa262f57c8 Poland | |
| 91c45274-ac57-47f7-b9d3-deea7564b36e Portugal | |
| 1b9f704f-b5cc-4593-b2de-ae6a0378d041 Sweden | |
| 391926c9-43e3-4f3d-9800-27097cd3bcf4 Finland | |
| b36c8d6f-5b11-4860-b726-388f180d899a Norway | |
| f8121e8b-3d4d-48f2-a338-0a68f7f37776 Belgium | |
| 8b42da4a-3980-4e80-81f7-6fdaa1325bf0 Germany | |
| c8755f76-2a3b-47c2-86d0-8cceb8d15c73 France | |
| 682b99ad-70bb-4dbf-8618-1c4fabda415d Spain | |
| 39bdaf5f-795f-47f7-b5f0-60ad7ef7f158 Hungary | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| Order Code US and Canada | XT5HE440AFFF000XXX |
| E-Number (Norway) | 4380440 |
| EAN | 8056221006088 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 186 mm |
| Product Net Height | 205 mm |
| Product Net Depth / Length | 103.5 mm |
| Product Net Weight | 6.4 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 250 mm |
| Package Level 1 Height | 245 mm |
| Package Level 1 Depth / Length | 285 mm |
| Package Level 1 Gross Weight | 6.888 kg |
| Package Level 1 EAN | 8056221006088 |
| Additional Information | |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| CAD Dimensional Drawing | 1SDH002065A1183 |
| 1SDH002065A1131 | |
| Technical | |
| Current Type | AC |
| Electrical Durability | 7000 cycle |
| 60 cycles per hour | |
| Mechanical Durability | 20000 cycle |
| 120 cycles per hour | |
| Number of Poles | 4P |
| Order Multiple | 1 piece |
| Power Loss | 19 W |
| Rated Current (In) | 400 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 50 kA | |
| (690 V AC) 40 kA | |
| Rated Short-time Withstand Current Low Voltage (Icw) | 5 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 50 kA | |
| (690 V AC) 40 kA | |
| Rated Uninterrupted Current (Iu) | 400 A |
| Release | Ekip Dip LSI |
| Release Type | EL |
| Short-Circuit Performance Level | H |
| Standards | IEC60947-2 |
| Sub-type | XT5 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK107680A2824 |
| EU Data Act Compliance Declaration | 1SDH002560A1001 |
| Mechanical Drawings | 1SDH002011A1101 |
| Wiring Diagram | 1SDM000005A1001 |
| Instructions and Manuals | 1SDH002011A1001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
