ABB 1SDA100528R1 1SDA100528R1 ABB XT5H 400 Ekip Dip LS/I In 400 4p F F View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA100528R1 ABB XT5H 400 Ekip Dip LS/I In 400 4p F F

1SDA100528R1

100528

ABB

1 Pcs.

XT5H 400 Ekip Dip LS/I In=400 4p F F

Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
ABB EcoSolutions
ABB EcoSolutionsYes
ABB Site Meeting Group Waste To Landfill TargetUL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions9AKK108468A2354
Environmental Product Declaration - EPD9AKK108468A1899
9AKK108468A9748
Extended Product LifetimeProduct Modularity
Recyclability Rate of the Product acc. to EN45555Design for Closing Resource Loops - Standard EN45555 - 59.6 %
Material Compliance
REACH Declaration9AKK108466A1425
RoHS Declaration9AKK108466A1424
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Toxic Substances Control Act - TSCA9AKK108467A8326
SCIPa7ef41be-c36c-4c47-9da6-f55d9ce76be4 Italy
Simplified SCIP5118ca37-ebca-4c6e-a1ac-993116e283ed Sweden
25cd2d3e-7a8b-4029-9246-d291aa64c4ed Greece
0193b50c-7f70-4d9d-8ca1-6888812e618e Estonia
75626fa3-acfb-44b6-929f-db2750a319ca Germany
4d62e5bb-e82d-461f-baa1-55707b06cca2 Poland
4bd0f1c8-eb76-43e5-88fb-13229f6ef056 Netherlands
4cca1f7f-6562-4590-8719-96916e70fed8 Poland
eb88f300-2d54-4215-9117-75ff64a7eb79 Denmark
0b4ad95a-d10e-4e7f-9236-0f57dc150197 Germany
10882c45-c4d6-4c35-847f-2a707c64e0f0 Croatia
630e6a09-1826-40f7-8e64-0f0dc3891546 Czech Republic
17d83e4c-b0bd-42f3-8e6c-65e1fc943748 Belgium
5b69f8c9-aacf-44e1-b1fb-abc356c123c9 Germany
6e342f23-5658-4520-80b3-0e6311c23814 Finland
1ec890c2-c367-4d16-8837-e69eccac4ce9 Norway
43d42d23-381b-4a95-b440-1e619ffb316e Spain
41c83cc0-985c-4ae6-a2c5-964ad1569a1e Hungary
2535af33-bfe2-4a77-9cbe-b755043ad7e8 Belgium
cf8eb4d8-e98e-40f5-abf6-cc50d40a7b42 Germany
347ce8e9-f6e8-45c3-a174-83741e1d9703 France
e7be9293-44c1-4789-b1c5-1c4106bb3c30 Hungary
8821388b-0fef-44a4-9456-78587de874f6 Sweden
f55a1ed5-063c-440c-8526-dd84051aa852 Germany
b2912c4d-210b-4539-af76-8fe6dfe6e09b France
f8c8a916-cdb7-4f90-8988-db41c52eed6c Poland
64007632-fb14-4209-a17f-ca3d6d041bb5 Portugal
b2dcc1df-849f-4612-961a-d9dc562d24e8 Bulgaria
Environmental
Environmental Information9AKK108467A6707
Ordering
Order Code US and CanadaXT5HE440AEFF000XXX
E-Number (Norway)4380436
EAN8056221006040
Minimum Order Quantity1 piece
Customs Tariff Number85362090
Dimensions
Product Net Width186 mm
Product Net Height205 mm
Product Net Depth / Length103.5 mm
Product Net Weight6.4 kg
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width250 mm
Package Level 1 Height245 mm
Package Level 1 Depth / Length285 mm
Package Level 1 Gross Weight6.888 kg
Package Level 1 EAN8056221006040
Additional Information
Circuit Breaker Type to be AssociatedPower Distribution
Product Main TypeSACE Tmax XT
Product NameMoulded Case Circuit Breaker
Product TypeAutomatic Circuit Breaker
VersionF
CAD Dimensional Drawing1SDH002065A1183
1SDH002065A1131
Technical
Current TypeAC
Electrical Durability7000 cycle
60 cycles per hour
Mechanical Durability20000 cycle
120 cycles per hour
Number of Poles4P
Order Multiple1 piece
Power Loss19 W
Rated Current (In)400 A
Rated Impulse Withstand Voltage (Uimp)8 kV
Rated Insulation Voltage (Ui)1000 V
Rated Operational Voltage690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics)(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 50 kA
(690 V AC) 40 kA
Rated Short-time Withstand Current Low Voltage (Icw)5 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu)(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 50 kA
(690 V AC) 40 kA
Rated Uninterrupted Current (Iu)400 A
ReleaseEkip Dip LS/I
Release TypeEL
Short-Circuit Performance LevelH
StandardsIEC60947-2
Sub-typeXT5
Terminal Connection TypeFront
Certificates and Declarations
Data Sheet, Technical Information1SDC210100D0206
1SDC210099D0206
Declaration of Conformity - CE9AKK107680A2824
EU Data Act Compliance Declaration1SDH002560A1001
Mechanical Drawings1SDH002011A1101
Wiring Diagram1SDM000005A1001
Instructions and Manuals1SDH002011A1001
External Classifications and Standards
ETIM 9EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification CodeQ
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
eClassV11.1 : 27370409

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
