1SDA100526R1 ABB XT5H 400 Ekip Dip LS/I In 250 4p F F
1SDA100526R1
100526
ABB
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Power distribution networks rely heavily on the 1SDA100526R1 ABB XT5H 400 Ekip Dip LS/I In 250 4p F F molded case circuit breaker manufactured by Abb. Such components provide essential safeguards, interrupting dangerous fault currents before they can harm downstream electrical equipment.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- ABB Site Meeting Group Waste To Landfill Target: UL 2799 Zero Waste To Landfill Validation available
- End Of Life Disassembling Instructions: 9AKK108468A2354
- Environmental Product Declaration - EPD: 9AKK108468A1899
- Extended Product Lifetime: Product Modularity
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 59.6 %
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- SCIP: 8058cc54-6eb9-40ae-bb55-8c768e1f7be1 Italy
- Simplified SCIP: 7a7842e2-eb6f-493c-a3d5-45eb370d6649 Germany
- Environmental Information: 9AKK108467A6707
- Order Code US and Canada: XT5HE425AEFF000XXX
- E-Number (Norway): 4380434
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2354 |
| Environmental Product Declaration - EPD | 9AKK108468A1899 |
| 9AKK108468A9748 | |
| Extended Product Lifetime | Product Modularity |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 59.6 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | 8058cc54-6eb9-40ae-bb55-8c768e1f7be1 Italy |
| Simplified SCIP | 7a7842e2-eb6f-493c-a3d5-45eb370d6649 Germany |
| a822e1f4-1c87-455c-8274-31593deb41e2 Portugal | |
| ab4698c2-e1cc-4e93-8daa-ca22912aeb57 Denmark | |
| b0307c80-7ec4-4763-a991-eae4905cbac1 Bulgaria | |
| b3358b86-fc02-45f1-ad05-9da7fe69dacd Poland | |
| acdbb642-00c8-4774-af1e-c89968fb27ec Sweden | |
| 6c6dd90b-c3f0-4341-9e7e-09dfae07ebc4 Poland | |
| 5a507b9e-25c1-48a7-bef4-cbcca92a9ef2 France | |
| 9818a3f6-d79f-474e-a200-fb6c31a91689 Sweden | |
| fb93b274-d667-46ee-a132-9f67e23b8a0e Germany | |
| e0adb585-2c17-4db1-9539-fa7155b10ca8 Norway | |
| 75a23986-7058-480b-93fd-8486bc13d1db Germany | |
| 33ed6c3f-3374-41f3-bec9-d776176a6f65 Czech Republic | |
| e079af9d-56a4-42a9-9822-8cdd2b2ee98b Belgium | |
| c7ada89a-0d42-4d73-95da-174d9aaa2536 Croatia | |
| 4568bc34-864b-4944-9d7a-8113b1346405 Finland | |
| a1721e1d-d513-45c1-8be5-afa0b4dcf1c5 Hungary | |
| f0c378c5-a369-483e-8327-a8cc120f65d3 France | |
| 775b8081-bc1e-47ea-9723-59704cf5d86c Germany | |
| 666f7099-225e-436a-91a1-7b8b1540e1cd Poland | |
| d4397df4-9dc5-4801-861c-c4018781aedf Germany | |
| 77f4cf09-e077-4942-9779-faa662e64ac4 Spain | |
| 7ef025ee-aa57-42b6-b39c-885337fa19e4 Netherlands | |
| a20b03a8-85b3-484b-9bfc-d0c6da10ad57 Belgium | |
| 542ff5bf-86f1-4ba9-905c-a59095a33e5a Hungary | |
| 1068fe02-e114-4f98-a38a-2adf68f72ae9 Estonia | |
| 9c1e2806-d769-49fd-95a4-a5ce294fc576 Greece | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| Order Code US and Canada | XT5HE425AEFF000XXX |
| E-Number (Norway) | 4380434 |
| EAN | 8056221006026 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 186 mm |
| Product Net Height | 205 mm |
| Product Net Depth / Length | 103.5 mm |
| Product Net Weight | 6.4 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 250 mm |
| Package Level 1 Height | 245 mm |
| Package Level 1 Depth / Length | 285 mm |
| Package Level 1 Gross Weight | 6.888 kg |
| Package Level 1 EAN | 8056221006026 |
| Additional Information | |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| CAD Dimensional Drawing | 1SDH002065A1183 |
| 1SDH002065A1131 | |
| Technical | |
| Current Type | AC |
| Electrical Durability | 7000 cycle |
| 60 cycles per hour | |
| Mechanical Durability | 20000 cycle |
| 120 cycles per hour | |
| Number of Poles | 4P |
| Order Multiple | 1 piece |
| Power Loss | 8 W |
| Rated Current (In) | 250 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 50 kA | |
| (690 V AC) 40 kA | |
| Rated Short-time Withstand Current Low Voltage (Icw) | 5 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 50 kA | |
| (690 V AC) 40 kA | |
| Rated Uninterrupted Current (Iu) | 400 A |
| Release | Ekip Dip LS/I |
| Release Type | EL |
| Short-Circuit Performance Level | H |
| Standards | IEC60947-2 |
| Sub-type | XT5 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK107680A2824 |
| EU Data Act Compliance Declaration | 1SDH002560A1001 |
| Mechanical Drawings | 1SDH002011A1101 |
| Wiring Diagram | 1SDM000005A1001 |
| Instructions and Manuals | 1SDH002011A1001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
