1SDA100515R1 ABB XT5H 400 Ekip Dip LIG In 320 3p F F
1SDA100515R1
100515
ABB
1 Pcs.
XT5H 400 Ekip Dip LIG In=320 3p F F
Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An Abb 1SDA100515R1 circuit breaker safeguards industrial distribution circuits by automatically interrupting excessive current during overloads and short circuits. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- ABB Site Meeting Group Waste To Landfill Target: UL 2799 Zero Waste To Landfill Validation available
- End Of Life Disassembling Instructions: 9AKK108468A2354
- Environmental Product Declaration - EPD: 9AKK108468A1899
- Extended Product Lifetime: Product Modularity
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 59.6 %
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- SCIP: 592f771a-bb56-4d46-91b3-82d42c6f12a0 China
- Simplified SCIP: ec0fdad7-ed57-4942-990d-6b6b90141e88 Portugal
- Environmental Information: 9AKK108467A6707
- Order Code US and Canada: XT5HE332ACFF000XXX
- EAN: 8056221005920
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2354 |
| Environmental Product Declaration - EPD | 9AKK108468A1899 |
| 9AKK108468A9748 | |
| Extended Product Lifetime | Product Modularity |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 59.6 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | 592f771a-bb56-4d46-91b3-82d42c6f12a0 China |
| Simplified SCIP | ec0fdad7-ed57-4942-990d-6b6b90141e88 Portugal |
| 03bd6526-5698-4507-a80c-166d5b2fb9e2 Estonia | |
| d7ee7d3e-30bf-4db1-8b80-39139ab5c34b Poland | |
| 32ff158d-8a10-45b6-9c9b-da5b6273cb2d Poland | |
| f6307873-7608-4bed-9c3b-f4073cc69d01 Germany | |
| 568bc047-7a15-4408-8b86-f0271f23c353 Netherlands | |
| 140ecea9-342e-4b08-809c-1db8532490dd Czech Republic | |
| 2744f84b-2ddd-45b9-80b0-0779829d7619 Greece | |
| 7368f2ac-074a-40c6-a14a-b0b3c2504179 Sweden | |
| f6e92108-83ba-4477-b4be-ebf406bca7dc Germany | |
| 01e9d84f-b54f-4bda-a29b-a4a3f4c0396f Bulgaria | |
| 6feec443-93d3-4d45-8c7a-892edaa58fae Germany | |
| e2d72519-5065-4f4b-a9bd-e980546d0904 Poland | |
| 2043224f-997a-4f0a-867e-fdb10c5c1474 Spain | |
| 9dbc59a2-f10e-480c-9ff7-c127f1aa9ea0 Sweden | |
| 6a6ccc0c-f4a9-4eca-b732-963e70ce6257 Norway | |
| a536db20-7557-4429-8f61-48de487e3465 Denmark | |
| 0ac9897a-b1e7-4ea2-9d61-5c958de358d6 Hungary | |
| de2849b1-5fb4-42e7-92f9-94d98b22fb22 Hungary | |
| d2329bf2-8158-4f10-b59e-0e63243f2075 France | |
| d30ea895-c103-48d7-bc0f-56dc5091a702 Germany | |
| c8f551df-6370-4803-997e-b02acb785366 Belgium | |
| a92bf16b-7f14-41a4-bf63-afb48df8ac9b Finland | |
| c34c5d6f-32a8-4f72-bbd6-eec1df363c8b France | |
| 9a26a809-1668-4317-afdb-139d096b988b Germany | |
| de35e480-e821-4cca-98f0-515922b6df7a Belgium | |
| 50880611-f9d9-4559-8ba8-4af6c5818beb Croatia | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| Order Code US and Canada | XT5HE332ACFF000XXX |
| EAN | 8056221005920 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 140 mm |
| Product Net Height | 205 mm |
| Product Net Depth / Length | 103.5 mm |
| Product Net Weight | 4.82 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 250 mm |
| Package Level 1 Height | 245 mm |
| Package Level 1 Depth / Length | 285 mm |
| Package Level 1 Gross Weight | 5.308 kg |
| Package Level 1 EAN | 8056221005920 |
| Additional Information | |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| CAD Dimensional Drawing | 1SDH002065A1115 |
| 1SDH002065A1131 | |
| Technical | |
| Current Type | AC |
| Electrical Durability | 7000 cycle |
| 60 cycles per hour | |
| Mechanical Durability | 20000 cycle |
| 120 cycles per hour | |
| Number of Poles | 3P |
| Order Multiple | 1 piece |
| Power Loss | 11.6 W |
| Rated Current (In) | 320 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 50 kA | |
| (690 V AC) 40 kA | |
| Rated Short-time Withstand Current Low Voltage (Icw) | 5 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 50 kA | |
| (690 V AC) 40 kA | |
| Rated Uninterrupted Current (Iu) | 400 A |
| Release | Ekip Dip LIG |
| Release Type | EL |
| Short-Circuit Performance Level | H |
| Standards | IEC60947-2 |
| Sub-type | XT5 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK107680A2824 |
| EU Data Act Compliance Declaration | 1SDH002560A1001 |
| Mechanical Drawings | 1SDH002011A1101 |
| Wiring Diagram | 1SDM000005A1001 |
| Instructions and Manuals | 1SDH002011A1001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
