1SDA100428R1 ABB XT5S 400 Ekip Dip LSI In 400 3p F F
1SDA100428R1
100428
ABB
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A moulded case circuit breaker, specifically the Abb 1SDA100428R1 ABB XT5S 400 Ekip Dip LSI In 400 3p F F, provides dependable overcurrent and short-circuit protection for power distribution architectures. Industrial facilities rely on such devices to safeguard critical electrical circuits and downstream machinery from faults and thermal overloads.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- ABB EcoSolutions: Yes
- ABB Site Meeting Group Waste To Landfill Target: UL 2799 Zero Waste To Landfill Validation available
- End Of Life Disassembling Instructions: 9AKK108468A2354
- Environmental Product Declaration - EPD: 9AKK108468A1899
- Extended Product Lifetime: Product Modularity
- Recyclability Rate of the Product acc. to EN45555: Design for Closing Resource Loops - Standard EN45555 - 59.6 %
- REACH Declaration: 9AKK108466A1425
- RoHS Declaration: 9AKK108466A1424
- RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
- Conflict Minerals Reporting Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- SCIP: a1379105-3fc0-4aba-b415-756d94efb8c3 Italy
- Simplified SCIP: 38bf92bc-2fba-4537-b384-aabc5207ac77 Germany
- Environmental Information: 9AKK108467A6707
- Order Code US and Canada: XT5SE340AFFF000XXX
- E-Number (Finland): 3641344
More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2354 |
| Environmental Product Declaration - EPD | 9AKK108468A1899 |
| 9AKK108468A9748 | |
| Extended Product Lifetime | Product Modularity |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 59.6 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | a1379105-3fc0-4aba-b415-756d94efb8c3 Italy |
| Simplified SCIP | 38bf92bc-2fba-4537-b384-aabc5207ac77 Germany |
| 53ebf2d7-d71c-4159-a52e-f2cdcb5e2e39 Poland | |
| 75d5d7d1-42bf-4aa3-927f-8ef2fddcc2f2 Belgium | |
| 8c2b787e-bfba-40e2-8d99-388cac328344 Finland | |
| b5f9c94d-4c05-4197-bcc1-d85874f01db4 Germany | |
| e2d83999-a768-4a86-a18b-df4513b6b3a2 Denmark | |
| 2a5727a6-b5b6-4aa5-ab7d-86465c86e534 Germany | |
| b065a738-64f9-48ce-a439-7d7cac13a65d Croatia | |
| 2f329efc-f31b-44ff-9610-606b77d3292a Czech Republic | |
| 495b19b1-2d8d-49f6-8987-719b1bdbe289 Spain | |
| 06d8ef21-e93c-44a5-9f74-1f16d028bcf3 Belgium | |
| 5656904c-d923-45d7-a417-704759bd43ec Germany | |
| 6977ec16-8f26-4f2b-858e-3700f6723530 Hungary | |
| a53bec79-ef86-4641-a8be-53c043b63e3e France | |
| dcc08190-2bf5-47c0-bd8b-6af1076a7612 Estonia | |
| 20321492-c781-472c-869e-a91b246dd417 Greece | |
| 05b514f7-b7cf-4d71-8956-2148d0aabea7 Bulgaria | |
| 86f2a9f5-acbb-4fb8-8a26-0b1b47f320ab Portugal | |
| d8d4e340-046e-4dc4-9f97-d2a5ee80189f Sweden | |
| 01938fd5-00ad-4c31-91ec-cd8578bb2ba4 France | |
| 2a63df21-5e82-43fd-864a-35a9fffd9ed8 Sweden | |
| 6cdcbfc0-ff00-46d9-a9f6-8da535e01d33 Poland | |
| 2faa5a70-066c-4e07-b593-ca397257d3ca Hungary | |
| ec680747-355e-4fd3-9a1f-d9ba1cf4652c Poland | |
| 25929399-1b03-4d53-ba3f-fc799f47bc67 Norway | |
| e473b2e6-d4e4-4a93-9e77-8958565a9926 Germany | |
| 4d491ee8-e9b6-4bf6-95fd-c19d2710d94d Netherlands | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| Order Code US and Canada | XT5SE340AFFF000XXX |
| E-Number (Finland) | 3641344 |
| E-Number (Norway) | 4380279 |
| EAN | 8056221005050 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 140 mm |
| Product Net Height | 205 mm |
| Product Net Depth / Length | 103.5 mm |
| Product Net Weight | 4.82 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 250 mm |
| Package Level 1 Height | 245 mm |
| Package Level 1 Depth / Length | 285 mm |
| Package Level 1 Gross Weight | 5.308 kg |
| Package Level 1 EAN | 8056221005050 |
| Additional Information | |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Automatic Circuit Breaker |
| Version | F |
| CAD Dimensional Drawing | 1SDH002065A1115 |
| 1SDH002065A1131 | |
| Technical | |
| Current Type | AC |
| Electrical Durability | 7000 cycle |
| 60 cycles per hour | |
| Mechanical Durability | 20000 cycle |
| 120 cycles per hour | |
| Number of Poles | 3P |
| Order Multiple | 1 piece |
| Power Loss | 19 W |
| Rated Current (In) | 400 A |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 85 kA |
| (230 V AC) 85 kA | |
| (240 V AC) 85 kA | |
| (380 V AC) 50 kA | |
| (415 V AC) 50 kA | |
| (440 V AC) 50 kA | |
| (500 V AC) 30 kA | |
| (525 V AC) 30 kA | |
| (690 V AC) 25 kA | |
| Rated Short-time Withstand Current Low Voltage (Icw) | 5 kA |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 85 kA |
| (230 V AC) 85 kA | |
| (240 V AC) 85 kA | |
| (380 V AC) 50 kA | |
| (415 V AC) 50 kA | |
| (440 V AC) 50 kA | |
| (500 V AC) 30 kA | |
| (525 V AC) 30 kA | |
| (690 V AC) 25 kA | |
| Rated Uninterrupted Current (Iu) | 400 A |
| Release | Ekip Dip LSI |
| Release Type | EL |
| Short-Circuit Performance Level | S |
| Standards | IEC60947-2 |
| Sub-type | XT5 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK107680A2824 |
| EU Data Act Compliance Declaration | 1SDH002560A1001 |
| Mechanical Drawings | 1SDH002011A1101 |
| Wiring Diagram | 1SDM000005A1001 |
| Instructions and Manuals | 1SDH002011A1001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
