> ABB > Molded case "Isomax-Tmax" > 100427
ABB 1SDA100427R1 1SDA100427R1 ABB XT5S 400 Ekip Dip LSI In 320 3p F F View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA100427R1 ABB XT5S 400 Ekip Dip LSI In 320 3p F F

1SDA100427R1

100427

ABB

1 Pcs.

XT5S 400 Ekip Dip LSI In=320 3p F F

Automation > Power circuit-breaker for trafo/generator/installation protection
Molded case "Isomax-Tmax"

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
ABB EcoSolutions
ABB EcoSolutionsYes
ABB Site Meeting Group Waste To Landfill TargetUL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions9AKK108468A2354
Environmental Product Declaration - EPD9AKK108468A1899
9AKK108468A9748
Extended Product LifetimeProduct Modularity
Recyclability Rate of the Product acc. to EN45555Design for Closing Resource Loops - Standard EN45555 - 59.6 %
Material Compliance
REACH Declaration9AKK108466A1425
RoHS Declaration9AKK108466A1424
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
Toxic Substances Control Act - TSCA9AKK108467A8326
SCIPa05e6640-5072-4301-a268-8feee5e25290 China
Simplified SCIP786140bf-43ce-47b6-b243-571e1b03f34d Greece
154452c4-8020-48fa-b5c6-def6cb13f283 Germany
b43f0540-7ecb-42fe-996f-4cfc01fe67f2 Poland
4830464f-2f9f-4db2-8dd3-3d4b1861b6ff Sweden
0fc30ecb-e767-4cd8-9070-0e2f1a24fa89 Portugal
e113eb7a-08db-46c6-a43c-14fa12d0992b Netherlands
01a45ca5-7bdc-484d-a861-223b35a1cc08 Sweden
4fccff8f-9298-4e98-9271-3c667e3f60b3 Poland
8e221cb4-29ab-497b-b624-4ac3dd1418f6 Finland
0ea00e36-8eea-45db-ae3d-47b5e039e0fe Poland
b0959c20-0b88-4b8c-a71f-8e548ce47bef Croatia
9c224be4-a8fb-4a38-a098-bef09afbe4e2 Czech Republic
5f1b6bdb-2795-4e47-a2fd-b1e0b37c8e39 Norway
60ddf15a-d840-4c0c-ae5c-37b851e4c0c0 Hungary
2f6674b3-423b-42bf-97e2-9765a8bfabe6 Spain
48f06730-fd8e-4cb2-8402-36e35b2811b3 Denmark
4ba75cba-aae8-402a-a137-d529c11735d1 Belgium
753023d0-620b-4602-b826-87fe468dea91 Germany
810e5aa4-221d-49d9-9bd8-dbb962f25cb0 Germany
544a2d91-3db1-45ca-b915-6b889c79a5ff Germany
7abb8601-4a38-4039-a438-9a2a6f969e41 Belgium
692d132c-6ec7-47ba-86d7-96fc44c49520 Bulgaria
03e5a6af-cab9-4e76-beab-8a2ac2554c70 France
325cd129-f6ee-4190-8f77-bd7b0fd1f7a4 Estonia
fbdfb3e0-71e3-4287-9323-d0c32aaf5cbc France
7cedc3fd-96b0-4b65-af52-1aaf31751873 Germany
ff94c14d-c0fe-48c9-8ebf-273ccf3514a7 Hungary
Environmental
Environmental Information9AKK108467A6707
Ordering
Order Code US and CanadaXT5SE332AFFF000XXX
E-Number (Finland)3641342
E-Number (Norway)4380278
EAN8056221005043
Minimum Order Quantity1 piece
Customs Tariff Number85362090
Dimensions
Product Net Width140 mm
Product Net Height205 mm
Product Net Depth / Length103.5 mm
Product Net Weight4.82 kg
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width250 mm
Package Level 1 Height245 mm
Package Level 1 Depth / Length285 mm
Package Level 1 Gross Weight5.308 kg
Package Level 1 EAN8056221005043
Additional Information
Circuit Breaker Type to be AssociatedPower Distribution
Product Main TypeSACE Tmax XT
Product NameMoulded Case Circuit Breaker
Product TypeAutomatic Circuit Breaker
VersionF
CAD Dimensional Drawing1SDH002065A1115
1SDH002065A1131
Technical
Current TypeAC
Electrical Durability7000 cycle
60 cycles per hour
Mechanical Durability20000 cycle
120 cycles per hour
Number of Poles3P
Order Multiple1 piece
Power Loss11.6 W
Rated Current (In)320 A
Rated Impulse Withstand Voltage (Uimp)8 kV
Rated Insulation Voltage (Ui)1000 V
Rated Operational Voltage690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics)(220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 30 kA
(525 V AC) 30 kA
(690 V AC) 25 kA
Rated Short-time Withstand Current Low Voltage (Icw)5 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu)(220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 30 kA
(525 V AC) 30 kA
(690 V AC) 25 kA
Rated Uninterrupted Current (Iu)400 A
ReleaseEkip Dip LSI
Release TypeEL
Short-Circuit Performance LevelS
StandardsIEC60947-2
Sub-typeXT5
Terminal Connection TypeFront
Certificates and Declarations
Data Sheet, Technical Information1SDC210100D0206
1SDC210099D0206
Declaration of Conformity - CE9AKK107680A2824
EU Data Act Compliance Declaration1SDH002560A1001
Mechanical Drawings1SDH002011A1101
Wiring Diagram1SDM000005A1001
Instructions and Manuals1SDH002011A1001
External Classifications and Standards
ETIM 9EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification CodeQ
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
eClassV11.1 : 27370409

ETIM for 1SDA100427R1 Low-voltage industrial controls and switchgear (EC000228)
Feature Name Feature Value
Rated permanent current Iu (EF001389) 320 A
Rated voltage (EF003977) 690 V
Overload release current setting (EF002336) 128.0 A
Adjustment range short-term delayed short-circuit release (EF007129) 320 A
Adjustment range undelayed short-circuit release (EF007131) 320 A
Integrated earth fault protection (EF007296) No
Type of electrical connection of main circuit (EF006819) Bolt connection
Device construction (EF008240) Built-in device fixed built-in technique
Suitable for DIN rail (top hat rail) mounting (EF007250) No
DIN rail (top hat rail) mounting optional (EF008904) No
Number of auxiliary contacts as normally closed contact (EF001377) 0
Number of auxiliary contacts as normally open contact (EF001376) 0
Number of auxiliary contacts as change-over contact (EF003531) 0
With switched-off indicator (EF007006) No
With integrated under voltage release (EF001390) No
Number of poles (EF001391) 3
Position of connection for main current circuit (EF006671) Front
Type of control element (EF006976) Toggle
Complete device with protection unit (EF008906) Yes
Motor drive integrated (EF006697) No
Motor drive optional (EF007386) Yes
Degree of protection (IP) (EF005474) IP20
