1SDA100282R1 ABB Ekip Touch LSIG In 100A XT4 3p
1SDA100282R1
100282
ABB
1 Pcs.
Automation > Shunt release (for power circuit breaker)
Molded Case Circuit Breakers ≤ 250 A Xtmax
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
An ABB Ekip Touch LSIG In 100A XT4 3p solid-state trip unit delivers high-accuracy protection and measurement features for electrical distribution systems. These sophisticated releases enable operators to configure custom protection profiles for complex industrial networks.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Manufacturer: Abb
- Manufacturer part number: 1SDA100282R1
- Catalogue code: 100282
More info
▲b'
General Information
Ekip Touch LSIG In=100A XT4 3p
1SDA100282R1
8056221003360
Ekip Touch LSIG In=100A XT4 3p
SOLID-STATE RELEASE THREE-POLE IN AC EKIP TOUCH LSIG R 100 XT4
Ordering
8056221003360
1 piece
85389099
Dimensions
110 mm
100 mm
150 mm
1 kg
Container Information
1 piece
110 mm
100 mm
150 mm
1.1 kg
8056221003360
Additional Information
Power Distribution
Loose or configurable
AC
3
1 piece
Accessories for Tmax XT
Accessory
ACC
100 A
Ekip Touch LSIG
EL
IEC
XT4
Certificates and Declarations (Document Number)
Classifications
EC001023 - Shunt release (for power circuit breaker)
EC001023 - Shunt release (for power circuit breaker)
Q
5. Small Equipment (No External Dimension More Than 50 cm)
