ABB 1SDA100124R1 1SDA100124R1 ABB Ekip M Touch LRIU In 40A XT2 3p View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA100124R1 ABB Ekip M Touch LRIU In 40A XT2 3p

1SDA100124R1

100124

ABB

1 Pcs.

Ekip M Touch LRIU In=40A XT2 3p SOLID-STATE RELEASE THREE-POLE IN AC EKIP M TOUCH LRIU R 40 XT2

Automation > Shunt release (for power circuit breaker)
Molded Case Circuit Breakers ≤ 250 A Xtmax

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A motor protection release mechanism provides specialized monitoring and control inside industrial power distribution architectures, safeguarding heavy-duty electrical loads against thermal overloads and phase imbalances. Such devices allow operations teams to fine-tune trip curves specifically for motor starting characteristics and continuous running protection. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Manufacturer: Abb
  • Manufacturer part number: 1SDA100124R1
  • Catalogue code: 100124
  • Catalogue title: 1SDA100124R1 ABB Ekip M Touch LRIU In 40A XT2 3p
  • Product description: b' General Information Extended Product Type: Ekip M Touch LRIU In=40A XT2 3p Product ID: 1SDA100124R1 EAN: 8056221001786 Catalog Description: Ekip M Touch LRIU In=40A XT2 3p Long Description: SOLID-STATE RELEASE THREE-P
  • Manufacturer summary: Ekip M Touch LRIU In=40A XT2 3p SOLID-STATE RELEASE THREE-POLE IN AC EKIP M TOUCH LRIU R 40 XT2

More info

▲

b'

General Information

Extended Product Type:
Ekip M Touch LRIU In=40A XT2 3p
Product ID:
1SDA100124R1
EAN:
8056221001786
Catalog Description:
Ekip M Touch LRIU In=40A XT2 3p
Long Description:
SOLID-STATE RELEASE THREE-POLE IN AC EKIP M TOUCH LRIU R 40 XT2
\n

Ordering

EAN:
8056221001786
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85389099

Dimensions

Product Net Width:
110 mm
Product Net Height:
100 mm
Product Net Depth / Length:
150 mm
Product Net Weight:
1 kg

Container Information

Package Level 1 Units:
1 piece
Package Level 1 Width:
110 mm
Package Level 1 Height:
100 mm
Package Level 1 Depth / Length:
150 mm
Package Level 1 Gross Weight:
1.1 kg
Package Level 1 EAN:
8056221001786

Additional Information

Circuit Breaker Type to be Associated:
Motor Protection
Configuration Type:
Loose or configurable
Current Type:
AC
Number of Poles:
3
Order Multiple:
1 piece
Product Main Type:
Accessories for Tmax XT
Product Name:
Accessory
Product Type:
ACC
Rated Current (In):
40 A
Release:
Ekip M Touch LRIU
Release Type:
EL
Standards:
IEC
Suitable For:
XT2

Certificates and Declarations (Document Number)

Data Sheet, Technical Information:\n1SDC210100D0205
1SDC210099D0205
Instructions and Manuals:\n1SDH002031A1002

Classifications

ETIM 6:
EC001023 - Shunt release (for power circuit breaker)
ETIM 7:
EC001023 - Shunt release (for power circuit breaker)
Object Classification Code:
Q
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
