1SDA100098R1 ABB Ekip Dip LSIG In 100A XT2 3p
1SDA100098R1
1SDA100098R1
ABB
1 Pcs.
Automation > Shunt release (for power circuit breaker)
Molded Case Circuit Breakers ≤ 250 A Xtmax
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
ABB Ekip Dip LSIG In 100A XT2 3p components act as electronic trip units mounted within power distribution circuit breakers to monitor current levels and execute timed interruptions during electrical faults. They deliver reliable, adjustable protection for industrial assets against overloads and short circuits.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- REACH Declaration: 9AKK108466A1425
- RoHS Information: 9AKK108466A1424
- RoHS Status: Following EU Directive 2011/65/EU and Amendment 2015/863 22 July 2019
- Conflict Minerals Notification Template (CMRT): 9AKK108467A5658
- Toxic Substances Control Act - TSCA: 9AKK108467A8326
- Ean: 8056221001526
- Minimum order quantity: 1 piece
- Tariff code: 85389099
- Product Weight: 1 kg
- Packaging Level 1 Units: Box 1 piece
- Packaging Level 1 Width: 110 mm
- Packaging Level 1 High: 100 mm
- Level 1 Long Packaging: 150 mm
- Packaging Level 1 Weight: 1.1 kg
- EAN Level 1 Packaging: 8056221001526
- Type of circuit breaker to be associated: Power Distribution
More info
▲| ABB EcoSolutions | |
|---|---|
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Information | 9AKK108466A1424 |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 22 July 2019 |
| Conflict Minerals Notification Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| classification | |
| Ean | 8056221001526 |
| Minimum order quantity | 1 piece |
| Tariff code | 85389099 |
| Dimensions | |
| Product Weight | 1 kg |
| Packaging Information | |
| Packaging Level 1 Units | Box 1 piece |
| Packaging Level 1 Width | 110 mm |
| Packaging Level 1 High | 100 mm |
| Level 1 Long Packaging | 150 mm |
| Packaging Level 1 Weight | 1.1 kg |
| EAN Level 1 Packaging | 8056221001526 |
| Additional information | |
| Type of circuit breaker to be associated | Power Distribution |
| Main Product Type | Accessories for Tmax XT |
| Product Name | Accessory |
| Product Type | Accessory |
| Suitable for | XT2 |
| Suitable for product class | SACE Tmax XT |
| Technique | |
| Configuration Type | Loose or configurable |
| Current rate | Ac |
| Number of poles | 3P |
| Rated current (In) | 100 A |
| Release | Ekip Dip LSIG |
| Unlock Type | THE |
| Standards | IEC |
| Certificates and Declarations (Document Number) | |
| Technical data, technical information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | Refer to the EU Declaration of the relative Circuit Breaker |
| Instructions and manuals | 1SDH000721R0510 |
| 1SDH000721R0505 | |
| External Classifications and Standards | |
| ETIM 9 | EC001023 - Shunt release (for power circuit breaker) |
| ETIM 10 | EC001023 - Shunt release (for power circuit breaker) |
| Object Classification Code | Q |
| WEEE Category | 5. Small equipment (no external dimension more than 50cm) |
