1SDA100089R1 ABB XT2H 160 Ekip Dip LIG In 160A 4p F F
1SDA100089R1
100089
ABB
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Molded Case Circuit Breakers ≤ 250 A Xtmax
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Abb part number 1SDA100089R1 is a multi-pole circuit breaker configured to deliver robust protection across complex industrial electrical grids. Units of this specification are routinely utilized in main power distribution setups to manage loads and interrupt dangerous fault currents. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Manufacturer: Abb
- Manufacturer part number: 1SDA100089R1
- Catalogue code: 100089
- Catalogue title: 1SDA100089R1 ABB XT2H 160 Ekip Dip LIG In 160A 4p F F
- Product description: b' General Information Extended Product Type: XT2H 160 Ekip Dip LIG In=160A 4p F F Product ID: 1SDA100089R1 EAN: 8056221001434 Catalog Description: XT2H 160 Ekip Dip LIG In=160A 4p F F Long Description: C.BREAKER TMAX XT
- Manufacturer summary: XT2H 160 Ekip Dip LIG In=160A 4p F F C.BREAKER TMAX XT2H 160 FIXED FOUR-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP DIP LIG R 160
More info
▲b'
General Information
XT2H 160 Ekip Dip LIG In=160A 4p F F
1SDA100089R1
8056221001434
XT2H 160 Ekip Dip LIG In=160A 4p F F
C.BREAKER TMAX XT2H 160 FIXED FOUR-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP DIP LIG R 160
Ordering
8056221001434
1 piece
85362090
Dimensions
120 mm
130 mm
82.5 mm
1.5 kg
Container Information
1 piece
130 mm
208 mm
145 mm
1.6 kg
8056221001434
Additional Information
Power Distribution
AC
120 cycles per hour
8000 cycle
240 cycles per hour
25000 cycle
4
1 piece
at Rated Operating Conditions per Pole 16.1 W
SACE Tmax XT
Moulded Case Circuit Breaker
CB
160 A
8 kV
1000 V
690 V AC
(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 30 kA
(690 V AC) 15 kA
(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 30 kA
(690 V AC) 15 kA
160 A
Ekip Dip LIG
EL
H
IEC 60947
XT2
Fixed Circuit-Breakers
F
Certificates and Declarations (Document Number)
Classifications
EC000228 - Power circuit-breaker for trafo/generator/installation prot.
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Q
5. Small Equipment (No External Dimension More Than 50 cm)
