1SDA100086R1 ABB XT2H 160 Ekip Dip LIG In 25A 4p F F
1SDA100086R1
100086
ABB
1 Pcs.
Automation > Power circuit-breaker for trafo/generator/installation protection
Molded Case Circuit Breakers ≤ 250 A Xtmax
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The 1SDA100086R1 ABB XT2H 160 Ekip Dip LIG In 25A 4p F F is an advanced electronic circuit breaker engineered to provide precise trip characteristics for complex distribution grids. Modern electrical architectures rely on sophisticated protective devices to monitor current parameters and isolate faulted zones before critical machinery suffers damage. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Manufacturer: Abb
- Manufacturer part number: 1SDA100086R1
- Catalogue code: 100086
More info
▲b'
General Information
XT2H 160 Ekip Dip LIG In=25A 4p F F
1SDA100086R1
8056221001403
XT2H 160 Ekip Dip LIG In=25A 4p F F
C.BREAKER TMAX XT2H 160 FIXED FOUR-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP DIP LIG R 25 A
Ordering
8056221001403
1 piece
85362090
Dimensions
120 mm
130 mm
82.5 mm
1.5 kg
Container Information
1 piece
130 mm
208 mm
145 mm
1.6 kg
8056221001403
Additional Information
Power Distribution
AC
120 cycles per hour
8000 cycle
240 cycles per hour
25000 cycle
4
1 piece
at Rated Operating Conditions per Pole 0.8 W
SACE Tmax XT
Moulded Case Circuit Breaker
CB
25 A
8 kV
1000 V
690 V AC
(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 30 kA
(690 V AC) 15 kA
(220 V AC) 100 kA
(230 V AC) 100 kA
(240 V AC) 100 kA
(380 V AC) 70 kA
(415 V AC) 70 kA
(440 V AC) 65 kA
(500 V AC) 50 kA
(525 V AC) 30 kA
(690 V AC) 15 kA
160 A
Ekip Dip LIG
EL
H
IEC 60947
XT2
Fixed Circuit-Breakers
F
Certificates and Declarations (Document Number)
Classifications
EC000228 - Power circuit-breaker for trafo/generator/installation prot.
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Q
5. Small Equipment (No External Dimension More Than 50 cm)
