ABB 1SDA067388R1 1SDA067388R1 ABB Ekip TMA 200-2000 3P XT4 Relay View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SDA067388R1 ABB Ekip TMA 200-2000 3P XT4 Relay

1SDA067388R1

067388

ABB

1 Pcs.

Ekip TMA 200-2000 3P - XT4 Relay THERMOMAGNETIC RELEASE THREE-POLE IN AC-DC TMA R 200 I3=1000...2000 A XT4

Automation > Shunt release (for power circuit breaker)
Molded Case Circuit Breakers ≤ 250 A Xtmax

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A 1SDA067388R1 ABB Ekip TMA 200-2000 3P XT4 Relay is a specialized trip release unit designed to safeguard electrical distribution circuits against overloads and short circuits. Such components are typically installed inside molded case circuit breakers to monitor current flow and interrupt power when faults occur. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Manufacturer: Abb
  • Manufacturer part number: 1SDA067388R1
  • Catalogue code: 067388
  • Catalogue title: 1SDA067388R1 ABB Ekip TMA 200-2000 3P XT4 Relay
  • Product description: b' General Information Extended Product Type: TMA 200-2000 XT4 3p Product ID: 1SDA067388R1 EAN: 8015644012885 Catalog Description: TMA 200-2000 XT4 3p Long Description: THERMOMAGNETIC RELEASE THREE-POLE IN AC-DC TMA R 20;
  • Manufacturer summary: Ekip TMA 200-2000 3P - XT4 Relay THERMOMAGNETIC RELEASE THREE-POLE IN AC-DC TMA R 200 I3=1000...2000 A XT4

More info

▲

b'

General Information

Extended Product Type:
TMA 200-2000 XT4 3p
Product ID:
1SDA067388R1
EAN:
8015644012885
Catalog Description:
TMA 200-2000 XT4 3p
Long Description:
THERMOMAGNETIC RELEASE THREE-POLE IN AC-DC TMA R 200 I3=1000...2000 A XT4
\n

Ordering

EAN:
8015644012885
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85389099

Dimensions

Product Net Width:
162 mm
Product Net Height:
92 mm
Product Net Depth / Length:
100 mm
Product Net Weight:
1 kg

Container Information

Package Level 1 Units:
1 piece
Package Level 1 Width:
162 mm
Package Level 1 Height:
92 mm
Package Level 1 Depth / Length:
100 mm
Package Level 1 Gross Weight:
1.1 kg
Package Level 1 EAN:
8015644012885

Additional Information

Circuit Breaker Type to be Associated:
Power Distribution
Configuration Type:
Loose or configurable
Current Type:
AC/DC
Number of Poles:
3
Order Multiple:
1 piece
Product Main Type:
Accessories for Tmax XT
Product Name:
Accessory
Product Type:
ACC
Rated Current (In):
200 A
Release:
TMA
Release Type:
Thermomagnetic
Standards:
IEC
Suitable For:
XT4
Suitable for Product Class:
SACE Tmax XT

Certificates and Declarations (Document Number)

Data Sheet, Technical Information:\n1SDC210100D0205
1SDC210099D0205
Instructions and Manuals:\n1SDH000721R0505

Classifications

ETIM 6:
EC001023 - Shunt release (for power circuit breaker)
ETIM 7:
EC001023 - Shunt release (for power circuit breaker)
Object Classification Code:
Q
UNSPSC:
39120000
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
\n
'

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
