CA5X-01 Auxiliary contact block

Automation > Auxiliary contact block
Contactors and overload relays

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Abb auxiliary contact block is a reliable clip-on accessory configured to provide additional signaling poles for industrial contactors. These blocks help integrate feedback and safety interlock circuits within electrical control assemblies.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Minimum Order Quantity: 10 piece
  • Customs Tariff Number: 85030099
  • EPLAN Data: 9AAC167263_EPLAN
  • Data Sheet, Technical Information: 1SBC100187L0203
  • Instructions and Manuals: 1SBB910513D4501
  • CAD Dimensional Drawing: 2CDC001079B0201
  • Product Net Width: 10 mm
  • Product Net Depth / Length: 47 mm
  • Product Net Height: 36 mm
  • Product Net Weight: 0.014 kg
  • Number of Auxiliary Contacts NO: 0
  • Number of Auxiliary Contacts NC: 1
  • Rated Operational Voltage: Auxiliary Circuit 690 V
  • Conventional Free-air Thermal Current (I th ): acc. to IEC 60947-5-1, Θ = 40 °C 16 A
  • Rated Operational Current AC-15 (I e ): (690 V) 2 A
  • Rated Operational Current DC-13 (I e ): (24 V) 6 A / 144 W

More info

▲
Ordering
Minimum Order Quantity10 piece
Customs Tariff Number85030099
Popular Downloads
EPLAN Data9AAC167263_EPLAN
Data Sheet, Technical Information1SBC100187L0203
Instructions and Manuals1SBB910513D4501
CAD Dimensional Drawing2CDC001079B0201
Dimensions
Product Net Width10 mm
Product Net Depth / Length47 mm
Product Net Height36 mm
Product Net Weight0.014 kg
Technical
Number of Auxiliary Contacts NO0
Number of Auxiliary Contacts NC1
Rated Operational VoltageAuxiliary Circuit 690 V
Main Circuit 690 V
Conventional Free-air Thermal Current (Ith)acc. to IEC 60947-5-1, Θ = 40 °C 16 A
Rated Operational Current AC-15 (Ie)(690 V) 2 A
(24 / 127 V) 6 A
(220 / 240 V) 4 A
(380 / 400 V) 3 A
Rated Operational Current DC-13 (Ie)(24 V) 6 A / 144 W
(110 V) 0.55 A / 60 W
(125 V) 0.55 A / 69 W
(220 V) 0.30 A / 66 W
(250 V) 0.30 A / 75 W
(400 V) 2.8 A / 134 W
(500 V) 1 A / 72 W
Rated Short-time Withstand Current Low Voltage (Icw)for 0.1 s 140 A
for 1 s 100 A
Rated Insulation Voltage (Ui)acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 690 V
Maximum Electrical Switching Frequency(AC-15) 1200 cycles per hour
(DC-13) 900 cycles per hour
Maximum Mechanical Switching Frequency3600 cycles per hour
Terminal TypeScrew Terminals
Suitable ForAX06
AX09
AX12
AX18
AX25
AX32
AX40
AX50
AX65
AX80
AX95
AX115
AX150
NX
Product NameAuxiliary Contact Block
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration2CMT2021-006202
RoHS Declaration2CMT2021-006277
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA2CMT2023-006525
WEEE B2C / B2BBusiness To Business
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
ABB EcoSolutions
Certificates and Declarations
CB CertificateCB_CN28662
CCC CertificateCCC_2013010304656838
CCS CertificateCCS_GZ13T00025
CQC CertificateCQC2013010304656838
Declaration of Conformity - CCC2020980304001061
Declaration of Conformity - CE1SBD250013U1000
EAC CertificateEAC_RU C-DE ME77 B03562
UL CertificateUL-US-L252354-15-61406102-5
UL-CA-L252354-45-61406102-5
Container Information
Package Level 1 Unitsbox 10 piece
Package Level 1 Width65 mm
Package Level 1 Depth / Length130 mm
Package Level 1 Height40 mm
Package Level 1 Gross Weight0.14 kg
Package Level 1 EAN3471522387912
External Classifications and Standards
Object Classification CodeK
ETIM 7EC000041 - Auxiliary contact block
ETIM 8EC000041 - Auxiliary contact block
ETIM 9EC000041 - Auxiliary contact block
eClassV11.0 : 27371302
UNSPSC39121522
IDEA Granular Category Code (IGCC)4743 >> Auxiliary contact block
E-Number (Finland)3708078

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
