ABB 1SAM201902R1201 1SAM201902R1201 ABB HK1-11K Auxiliary contact View larger
Images are for illustrative purposes only. Please refer to data sheet for details

1SAM201902R1201 ABB HK1-11K Auxiliary contact

1SAM201902R1201

201902

ABB

1 Pcs.

HK1-11K Auxiliary contact HK1-11K Aux.-contact 1 NO + 1 NC with Push-In terminals

Automation > Auxiliary contact block
Electronic motor protection relays

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Abb auxiliary contact unit is a compact switching accessory that clips onto motor protection equipment to relay operational status data. Panel builders incorporate these units to provide remote indication and control interlocks for automated machinery.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Minimum Order Quantity: 1 piece
  • Customs Tariff Number: 85365080
  • Data Sheet, Technical Information: 1SBC100212C0201
  • Instructions and Manuals: 2CDC131120M6801
  • CAD Dimensional Drawing: 2CDC001079B0201
  • Marketing Video: 2CDC131130V0201
  • Product Net Width: 9 mm
  • Product Net Height: 90 mm
  • Product Net Depth / Length: 74.5 mm
  • Product Net Weight: 0.035 kg
  • Rated Operational Voltage: 690 V AC
  • Rated Impulse Withstand Voltage (U imp ): Auxiliary Circuit 6 kV
  • Rated Insulation Voltage (U i ): 690 V
  • Number of Auxiliary Contacts NC: 1
  • Number of Auxiliary Contacts NO: 1
  • Degree of Protection: IP20

More info

▲
Ordering
Minimum Order Quantity1 piece
Customs Tariff Number85365080
Popular Downloads
Data Sheet, Technical Information1SBC100212C0201
Instructions and Manuals2CDC131120M6801
CAD Dimensional Drawing2CDC001079B0201
Marketing Video2CDC131130V0201
Dimensions
Product Net Width9 mm
Product Net Height90 mm
Product Net Depth / Length74.5 mm
Product Net Weight0.035 kg
Technical
Rated Operational Voltage690 V AC
600 V DC
Rated Impulse Withstand Voltage (Uimp)Auxiliary Circuit 6 kV
Rated Insulation Voltage (Ui)690 V
Number of Auxiliary Contacts NC1
Number of Auxiliary Contacts NO1
Degree of ProtectionIP20
Electrical Durability100000 cycle
Mechanical DurabilityNr. Operations 100000 cycle
Terminal TypePush-in Spring Terminals
Connecting Capacity Auxiliary CircuitFlexible with Ferrule 1/2x 0.5 ... 2.5 mm²
Flexible with Insulated Ferrule 1/2x 0.5 ... 1.5 mm²
Flexible 1/2x 0.5 ... 2.5 mm²
Rigid 1/2x 0.5 ... 2.5 mm²
Wire Stripping LengthAuxiliary Circuit 10 mm
Recommended Screw DriverM3
Mounting Position1 ... 6
Technical UL/CSA
Maximum Operating Voltage UL/CSAMain Circuit 600 V AC
Connecting Capacity Auxiliary Circuit UL/CSARigid 1/2x 20-14 AWG
Stranded 1/2x 20-14 AWG
Contact Rating UL/CSAB600
Q600
Environmental
Ambient Air TemperatureOperation -25 ... +60 °C
Storage -50 ... +80 °C
Resistance to Shock acc. to IEC 60068-2-2711 ms Pulse 25g
Resistance to Vibrations5g 3 ... 150 Hz
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration1SAA963005-4502
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA2CMT2023-006539
WEEE B2C / B2BBusiness To Business
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
Certificates and Declarations
A2L Certificate – IEC1SAA963000-4601
ABS Certificate1SAA963001-0101
CB Certificate1SAA963004-2002
CCC Certificate2024010305656671
CQC CertificateCQC2017010304032778
Declaration of Conformity - CCC2020980304001252
Declaration of Conformity - CE1SAD101100-3410
Declaration of Conformity - UKCA1SAD201100-3410
RINA Certificate1SAA963002-0802
Container Information
Package Level 1 Unitsbox 2 piece
Package Level 1 Width25 mm
Package Level 1 Depth / Length80 mm
Package Level 1 Height93 mm
Package Level 1 Gross Weight0.08 kg
Package Level 1 EAN4013614523250
Package Level 2 Unitscarton 160 piece
Package Level 2 Width280 mm
Package Level 2 Depth / Length395 mm
Package Level 2 Height210 mm
Package Level 2 Gross Weight6.41 kg
Package Level 2 EAN4013614523427
External Classifications and Standards
Object Classification CodeQ
ETIM 9EC000041 - Auxiliary contact block
ETIM 10EC000041 - Auxiliary contact block
eClassV11.0 : 27371302
UNSPSC39121522
IDEA Granular Category Code (IGCC)4743 >> Auxiliary contact block
E-Number (Finland)3707824
E-Number (Norway)4364210
E-Number (Sweden)3110465

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
