1SAL204849R9906 ABB MP0DAE6 Surge Suppressor
1SAL204849R9906
204849
ABB
1 Pcs.
Automation > Surge protection module
Contactors and overload relays
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The ABB 1SAL204849R9906 surge suppressor absorbs transient voltages across control circuit paths, preventing electrical noise from disrupting sensitive automation components. Such suppressors are commonly integrated directly into control gear assemblies to ensure compliance with industrial immunity standards. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85363010
- EPLAN Data: 9AAC166197_EPLAN
- Data Sheet, Technical Information: 1SBC100214C0202
- Instructions and Manuals: 2CDC102078M9901
- CAD Dimensional Drawing: 2CDC001079B0201
- Product Net Width: 9 mm
- Product Net Depth / Length: 31 mm
- Product Net Height: 18 mm
- Product Net Weight: 0.006 kg
- Standards: IEC/EN 60947-1
- Rated Frequency (f): Control Circuit 50 Hz
- Rated Insulation Voltage (U i ): 750 V
- Rated Control Circuit Voltage (U c ): 130 ... 250 V AC
- Degree of Protection: IP20
- Terminal Type: No Terminals
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85363010 |
| Popular Downloads | |
| EPLAN Data | 9AAC166197_EPLAN |
| Data Sheet, Technical Information | 1SBC100214C0202 |
| Instructions and Manuals | 2CDC102078M9901 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Dimensions | |
| Product Net Width | 9 mm |
| Product Net Depth / Length | 31 mm |
| Product Net Height | 18 mm |
| Product Net Weight | 0.006 kg |
| Technical | |
| Standards | IEC/EN 60947-1 |
| IEC/EN 60947-4-1 | |
| UL 60947-1 | |
| UL 60947-4-1 | |
| Rated Frequency (f) | Control Circuit 50 Hz |
| Control Circuit 60 Hz | |
| Control Circuit DC | |
| Rated Insulation Voltage (Ui) | 750 V |
| Rated Control Circuit Voltage (Uc) | 130 ... 250 V AC |
| DC Operation 130 ... 250 V DC | |
| Degree of Protection | IP20 |
| Terminal Type | No Terminals |
| Suitable For | MC1 |
| MC2 | |
| MCR | |
| Suitable for Product Class | Mini Contactors |
| Product Name | Surge Suppressor |
| Environmental | |
| Ambient Air Temperature | Operation -25 ... +55 °C |
| Storage -55 ... +80 °C | |
| Maximum Operating Altitude Permissible | 3000 m |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006525 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| cULus Certificate | cUL_E48139 |
| Declaration of Conformity - CE | 1SAD101100-3201 |
| Declaration of Conformity - UKCA | 1SAD201100-3201 |
| RINA Certificate | 1SAA971000-0801 |
| Container Information | |
| Package Level 1 Units | bag 1 piece |
| Package Level 1 Width | 100 mm |
| Package Level 1 Depth / Length | 10 mm |
| Package Level 1 Height | 100 mm |
| Package Level 1 Gross Weight | 0.01 kg |
| Package Level 1 EAN | 4013614550560 |
| Package Level 2 Units | box 10 piece |
| Package Level 2 Width | 100 mm |
| Package Level 2 Depth / Length | 150 mm |
| Package Level 2 Height | 60 mm |
| Package Level 2 Gross Weight | 0.1 kg |
| Package Level 2 EAN | 4013614551031 |
| External Classifications and Standards | |
| Object Classification Code | F |
| ETIM 7 | EC000197 - Surge voltage protection |
| ETIM 8 | EC000683 - Surge protection module |
| ETIM 9 | EC000683 - Surge protection module |
| eClass | V11.0 : 27371010 |
| UNSPSC | 39121610 |
| E-Number (Finland) | 3709697 |
