1SAL100541R9906 ABB MREBC10AC2 Electronic Timer
1SAL100541R9906
100541
ABB
1 Pcs.
Automation > Accessories/spare parts for low-voltage switch technology
Contactors and overload relays
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Abb 1SAL100541R9906 MREBC10AC2 electronic timer regulates time-delayed switching operations in industrial control logic and automation sequences. Electronic timing relays provide precise interval control for motor starting, lighting circuits, and conveyor sequencing applications. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Minimum Order Quantity: 1 piece
- Customs Tariff Number: 85389091
- EPLAN Data: 9AAC166197_EPLAN
- Data Sheet, Technical Information: 1SBC100214C0202
- Instructions and Manuals: 2CDC102077M9901
- CAD Dimensional Drawing: 2CDC001079B0201
- Product Net Width: 35 mm
- Product Net Depth / Length: 36 mm
- Product Net Height: 21 mm
- Product Net Weight: 0.04 kg
- Standards: IEC/EN 60947-1
- Rated Operational Voltage: 24 ... 250 V AC/DC
- Rated Frequency (f): 50 / 60 Hz
- Rated Insulation Voltage (U i ): 750 V
- Rated Impulse Withstand Voltage (U imp ): 4 kV
- Rated Control Circuit Voltage (U c ): 24 ... 250 V
More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389091 |
| Popular Downloads | |
| EPLAN Data | 9AAC166197_EPLAN |
| Data Sheet, Technical Information | 1SBC100214C0202 |
| Instructions and Manuals | 2CDC102077M9901 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Dimensions | |
| Product Net Width | 35 mm |
| Product Net Depth / Length | 36 mm |
| Product Net Height | 21 mm |
| Product Net Weight | 0.04 kg |
| Technical | |
| Standards | IEC/EN 60947-1 |
| IEC/EN 60947-4-1 | |
| UL 60947-1 | |
| UL 60947-4-1 | |
| Rated Operational Voltage | 24 ... 250 V AC/DC |
| Rated Frequency (f) | 50 / 60 Hz |
| DC | |
| Rated Insulation Voltage (Ui) | 750 V |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Rated Control Circuit Voltage (Uc) | 24 ... 250 V |
| Degree of Protection | IP20 |
| Terminal Type | Screw Terminals |
| Timer Relay Type | ON-Delay |
| Suitable For | MC1 |
| MC2 | |
| MCR | |
| Suitable for Product Class | Mini Contactors |
| Product Name | Timer |
| Environmental | |
| Ambient Air Temperature | Operation -25 ... +55 °C |
| Storage -55 ... +80 °C | |
| Maximum Operating Altitude Permissible | 3000 m |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2021-006202 |
| RoHS Declaration | 2CMT2021-006277 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 1SAD101100-3202 |
| Declaration of Conformity - UKCA | 1SAD201100-3202 |
| UL Certificate | E48139-19930108 |
| Container Information | |
| Package Level 1 Units | bag 1 piece |
| Package Level 1 Width | 100 mm |
| Package Level 1 Depth / Length | 25 mm |
| Package Level 1 Height | 100 mm |
| Package Level 1 Gross Weight | 0.045 kg |
| Package Level 1 EAN | 4013614550492 |
| Package Level 2 Units | box 10 piece |
| Package Level 2 Width | 100 mm |
| Package Level 2 Depth / Length | 150 mm |
| Package Level 2 Height | 105 mm |
| Package Level 2 Gross Weight | 0.45 kg |
| Package Level 2 EAN | 4013614550966 |
| External Classifications and Standards | |
| Object Classification Code | K |
| ETIM 7 | EC002498 - Accessories for low-voltage switch technology |
| ETIM 8 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| ETIM 9 | EC002498 - Accessories/spare parts for low-voltage switch technology |
| eClass | V11.0 : 27371392 |
| UNSPSC | 39121529 |
| E-Number (Finland) | 3709742 |
